| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_123T11_9000005286_37236cztM0_level2.evt | modeM0/AS1A10_123T11_9000005286_37236cztM0_level2_quad_clean.evt |
| Size (bytes) | 487,117,440 | 74,741,760 |
| Size | 464.6 MB | 71.3 MB |
| Events in quadrant A | 3,173,134 | 474,553 |
| Events in quadrant B | 4,205,314 | 466,070 |
| Events in quadrant C | 3,230,835 | 460,104 |
| Events in quadrant D | 3,742,172 | 449,295 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13157 | 3 |
| B | 0 | 16433 | 2 |
| C | 0 | 13232 | 2 |
| D | 0 | 15133 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5913 | 53 | 0.896330% |
| B | 5913 | 192 | 3.247083% |
| C | 5913 | 117 | 1.978691% |
| D | 5913 | 132 | 2.232369% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7255 | 5913 | 34 | 34 | 0.47% | 0.58% |  |
| B | 7255 | 5914 | 100 | 100 | 1.38% | 1.69% |  |
| C | 7255 | 5914 | 96 | 96 | 1.32% | 1.62% |  |
| D | 7255 | 5914 | 114 | 114 | 1.57% | 1.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 310116 | 2297.22 | 666 | 650 | 134.7 |
| A | 9 | 143 | 119551 | 882.62 | 666 | 650 | 134.7 |
| A | 15 | 237 | 66146 | 486.19 | 666 | 650 | 134.7 |
| B | 0 | 190 | 480567 | 3754.29 | 657 | 639 | 127.8 |
| B | 5 | 172 | 213291 | 1663.49 | 657 | 639 | 127.8 |
| B | 4 | 232 | 192364 | 1499.79 | 657 | 639 | 127.8 |
| C | 15 | 214 | 247583 | 1625.52 | 647 | 652 | 151.9 |
| C | 0 | 10 | 217186 | 1425.42 | 647 | 652 | 151.9 |
| C | 1 | 23 | 96317 | 629.75 | 647 | 652 | 151.9 |
| D | 2 | 249 | 699658 | 4326.47 | 651 | 633 | 161.6 |
| D | 2 | 153 | 100438 | 617.72 | 651 | 633 | 161.6 |
| D | 2 | 250 | 77238 | 474.13 | 651 | 633 | 161.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
