| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_123T11_9000005286_37248cztM0_level2.evt | modeM0/AS1A10_123T11_9000005286_37248cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,213,824,320 | 402,560,640 |
| Size | 2.1 GB | 383.9 MB |
| Events in quadrant A | 16,373,302 | 2,716,973 |
| Events in quadrant B | 14,699,900 | 2,735,340 |
| Events in quadrant C | 13,228,352 | 2,661,790 |
| Events in quadrant D | 21,136,224 | 2,433,791 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 63016 | 5 |
| B | 0 | 58684 | 5 |
| C | 0 | 52883 | 5 |
| D | 0 | 78964 | 5 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 490 | 0 |
| B | 0 | 490 | 0 |
| C | 0 | 490 | 0 |
| D | 0 | 490 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 23901 | 1231 | 5.150412% |
| B | 23901 | 402 | 1.681938% |
| C | 23901 | 234 | 0.979039% |
| D | 23901 | 2452 | 10.258985% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 33976 | 23905 | 958 | 958 | 2.82% | 4.01% |  |
| B | 33976 | 23905 | 244 | 244 | 0.72% | 1.02% |  |
| C | 33976 | 23906 | 180 | 180 | 0.53% | 0.75% |  |
| D | 33976 | 23906 | 2277 | 2277 | 6.70% | 9.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 237 | 3610664 | 6432.63 | 2847 | 2800 | 560.9 |
| A | 10 | 83 | 1050851 | 1868.62 | 2847 | 2800 | 560.9 |
| A | 13 | 248 | 318044 | 562.06 | 2847 | 2800 | 560.9 |
| B | 0 | 230 | 662793 | 1241.66 | 2849 | 2782 | 531.6 |
| B | 0 | 190 | 653952 | 1225.03 | 2849 | 2782 | 531.6 |
| B | 12 | 18 | 511694 | 957.4 | 2849 | 2782 | 531.6 |
| C | 15 | 214 | 1012426 | 1602.6 | 2766 | 2790 | 630.0 |
| C | 14 | 254 | 621449 | 982.0 | 2766 | 2790 | 630.0 |
| C | 0 | 10 | 385591 | 607.62 | 2766 | 2790 | 630.0 |
| D | 10 | 253 | 4931213 | 7534.48 | 2699 | 2624 | 654.1 |
| D | 1 | 52 | 1293286 | 1973.07 | 2699 | 2624 | 654.1 |
| D | 2 | 249 | 1076689 | 1641.95 | 2699 | 2624 | 654.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
