| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_103T07_9000005302_37289cztM0_level2.evt | modeM0/AS1A10_103T07_9000005302_37289cztM0_level2_quad_clean.evt |
| Size (bytes) | 377,668,800 | 53,916,480 |
| Size | 360.2 MB | 51.4 MB |
| Events in quadrant A | 2,805,349 | 314,284 |
| Events in quadrant B | 2,612,556 | 325,004 |
| Events in quadrant C | 2,978,321 | 328,265 |
| Events in quadrant D | 2,697,660 | 310,218 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11182 | 3 |
| B | 0 | 10562 | 2 |
| C | 0 | 11669 | 2 |
| D | 0 | 11040 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 28 | 0 |
| D | 0 | 29 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5058 | 11 | 0.217477% |
| B | 5058 | 8 | 0.158165% |
| C | 5058 | 73 | 1.443258% |
| D | 5058 | 52 | 1.028074% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7152 | 5059 | 6 | 6 | 0.08% | 0.12% |  |
| B | 7152 | 5059 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7152 | 5059 | 58 | 58 | 0.81% | 1.15% |  |
| D | 7152 | 5059 | 42 | 42 | 0.59% | 0.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 260394 | 2040.6 | 636 | 625 | 127.3 |
| A | 9 | 143 | 24219 | 185.34 | 636 | 625 | 127.3 |
| A | 15 | 222 | 23681 | 181.11 | 636 | 625 | 127.3 |
| B | 0 | 213 | 33816 | 278.42 | 637 | 621 | 119.2 |
| B | 4 | 171 | 19932 | 161.97 | 637 | 621 | 119.2 |
| B | 0 | 189 | 17632 | 142.68 | 637 | 621 | 119.2 |
| C | 15 | 214 | 215617 | 1497.5 | 626 | 634 | 143.6 |
| C | 0 | 10 | 209481 | 1454.76 | 626 | 634 | 143.6 |
| C | 1 | 23 | 70304 | 485.3 | 626 | 634 | 143.6 |
| D | 1 | 52 | 128948 | 866.74 | 623 | 608 | 148.1 |
| D | 13 | 249 | 59064 | 394.78 | 623 | 608 | 148.1 |
| D | 2 | 250 | 24244 | 159.62 | 623 | 608 | 148.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
