| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_030T02_9000005310_37320cztM0_level2.evt | modeM0/AS1A11_030T02_9000005310_37320cztM0_level2_quad_clean.evt |
| Size (bytes) | 412,375,680 | 57,199,680 |
| Size | 393.3 MB | 54.5 MB |
| Events in quadrant A | 3,229,489 | 345,610 |
| Events in quadrant B | 2,894,401 | 350,268 |
| Events in quadrant C | 3,049,070 | 343,240 |
| Events in quadrant D | 2,962,292 | 328,092 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12738 | 3 |
| B | 0 | 11803 | 2 |
| C | 0 | 12117 | 2 |
| D | 0 | 12214 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5209 | 222 | 4.261854% |
| B | 5209 | 80 | 1.535803% |
| C | 5209 | 71 | 1.363026% |
| D | 5209 | 59 | 1.132655% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7272 | 5210 | 102 | 102 | 1.40% | 1.96% |  |
| B | 7272 | 5210 | 33 | 33 | 0.45% | 0.63% |  |
| C | 7272 | 5210 | 62 | 62 | 0.85% | 1.19% |  |
| D | 7272 | 5210 | 53 | 53 | 0.73% | 1.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 237 | 338704 | 2807.79 | 597 | 585 | 120.4 |
| A | 10 | 83 | 273035 | 2262.46 | 597 | 585 | 120.4 |
| A | 6 | 10 | 203973 | 1688.96 | 597 | 585 | 120.4 |
| B | 12 | 18 | 168702 | 1440.24 | 606 | 591 | 116.7 |
| B | 0 | 190 | 164988 | 1408.43 | 606 | 591 | 116.7 |
| B | 5 | 172 | 61004 | 517.57 | 606 | 591 | 116.7 |
| C | 1 | 23 | 330220 | 2383.9 | 594 | 599 | 138.3 |
| C | 15 | 214 | 219700 | 1584.59 | 594 | 599 | 138.3 |
| C | 0 | 10 | 131588 | 947.34 | 594 | 599 | 138.3 |
| D | 10 | 253 | 196211 | 1328.96 | 602 | 587 | 147.2 |
| D | 2 | 249 | 169360 | 1146.55 | 602 | 587 | 147.2 |
| D | 13 | 249 | 89256 | 602.37 | 602 | 587 | 147.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
