| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T11_9000005336_37566cztM0_level2.evt | modeM0/AS1C07_001T11_9000005336_37566cztM0_level2_quad_clean.evt |
| Size (bytes) | 407,992,320 | 97,436,160 |
| Size | 389.1 MB | 92.9 MB |
| Events in quadrant A | 2,599,084 | 645,189 |
| Events in quadrant B | 2,825,011 | 662,603 |
| Events in quadrant C | 2,686,890 | 662,138 |
| Events in quadrant D | 3,888,605 | 613,621 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11164 | 3 |
| B | 0 | 11852 | 2 |
| C | 0 | 11305 | 2 |
| D | 0 | 15278 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36 | 0 |
| B | 0 | 36 | 0 |
| C | 0 | 36 | 0 |
| D | 0 | 37 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5246 | 24 | 0.457491% |
| B | 5246 | 79 | 1.505909% |
| C | 5246 | 49 | 0.934045% |
| D | 5246 | 341 | 6.500191% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7339 | 5247 | 10 | 10 | 0.14% | 0.19% |  |
| B | 7339 | 5247 | 53 | 53 | 0.72% | 1.01% |  |
| C | 7339 | 5247 | 37 | 37 | 0.50% | 0.71% |  |
| D | 7339 | 5247 | 327 | 327 | 4.46% | 6.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 301165 | 2593.75 | 572 | 560 | 115.9 |
| A | 9 | 143 | 44828 | 381.96 | 572 | 560 | 115.9 |
| A | 13 | 6 | 12919 | 106.64 | 572 | 560 | 115.9 |
| B | 5 | 255 | 159915 | 1466.99 | 577 | 563 | 108.6 |
| B | 5 | 172 | 102068 | 934.45 | 577 | 563 | 108.6 |
| B | 0 | 213 | 65817 | 600.73 | 577 | 563 | 108.6 |
| C | 15 | 214 | 234884 | 1778.32 | 564 | 568 | 131.8 |
| C | 0 | 10 | 159364 | 1205.17 | 564 | 568 | 131.8 |
| C | 14 | 254 | 90912 | 685.66 | 564 | 568 | 131.8 |
| D | 2 | 249 | 504475 | 3760.02 | 546 | 529 | 134.0 |
| D | 2 | 250 | 438708 | 3269.32 | 546 | 529 | 134.0 |
| D | 10 | 199 | 288308 | 2147.17 | 546 | 529 | 134.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
