| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_057T01_9000005346_37790cztM0_level2.evt | modeM0/AS1T05_057T01_9000005346_37790cztM0_level2_quad_clean.evt |
| Size (bytes) | 397,304,640 | 61,522,560 |
| Size | 378.9 MB | 58.7 MB |
| Events in quadrant A | 3,106,308 | 369,549 |
| Events in quadrant B | 2,883,593 | 372,614 |
| Events in quadrant C | 2,816,203 | 372,922 |
| Events in quadrant D | 2,840,529 | 350,875 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12568 | 3 |
| B | 0 | 12011 | 2 |
| C | 0 | 11672 | 2 |
| D | 0 | 12306 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5669 | 49 | 0.864350% |
| B | 5669 | 16 | 0.282237% |
| C | 5669 | 19 | 0.335156% |
| D | 5669 | 49 | 0.864350% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7222 | 5670 | 29 | 29 | 0.40% | 0.51% |  |
| B | 7222 | 5670 | 8 | 8 | 0.11% | 0.14% |  |
| C | 7222 | 5670 | 5 | 5 | 0.07% | 0.09% |  |
| D | 7222 | 5670 | 47 | 47 | 0.65% | 0.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 346742 | 2633.95 | 646 | 635 | 131.4 |
| A | 9 | 143 | 176730 | 1340.12 | 646 | 635 | 131.4 |
| A | 13 | 248 | 44675 | 335.15 | 646 | 635 | 131.4 |
| B | 0 | 219 | 106881 | 854.47 | 644 | 627 | 124.3 |
| B | 0 | 229 | 51926 | 412.53 | 644 | 627 | 124.3 |
| B | 0 | 230 | 47586 | 377.63 | 644 | 627 | 124.3 |
| C | 15 | 214 | 263273 | 1767.54 | 633 | 636 | 148.6 |
| C | 0 | 10 | 60141 | 400.47 | 633 | 636 | 148.6 |
| C | 0 | 207 | 14565 | 93.74 | 633 | 636 | 148.6 |
| D | 13 | 249 | 109250 | 701.71 | 627 | 608 | 154.8 |
| D | 10 | 199 | 92767 | 595.24 | 627 | 608 | 154.8 |
| D | 1 | 47 | 41731 | 265.61 | 627 | 608 | 154.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
