| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_103T06_9000005348_37807cztM0_level2.evt | modeM0/AS1A10_103T06_9000005348_37807cztM0_level2_quad_clean.evt |
| Size (bytes) | 461,410,560 | 68,693,760 |
| Size | 440.0 MB | 65.5 MB |
| Events in quadrant A | 3,192,265 | 417,002 |
| Events in quadrant B | 3,751,860 | 418,887 |
| Events in quadrant C | 3,069,470 | 427,017 |
| Events in quadrant D | 3,551,942 | 396,943 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 34 | 0 |
| B | 0 | 34 | 0 |
| C | 0 | 34 | 0 |
| D | 0 | 34 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12967 | 3 |
| B | 0 | 15014 | 2 |
| C | 0 | 12577 | 2 |
| D | 0 | 14532 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6021 | 16 | 0.265737% |
| B | 6021 | 93 | 1.544594% |
| C | 6021 | 13 | 0.215911% |
| D | 6021 | 182 | 3.022754% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9368 | 6023 | 7 | 7 | 0.07% | 0.12% |  |
| B | 9368 | 6023 | 57 | 57 | 0.61% | 0.95% |  |
| C | 9368 | 6023 | 8 | 8 | 0.09% | 0.13% |  |
| D | 9368 | 6023 | 161 | 161 | 1.72% | 2.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 356458 | 2489.92 | 709 | 694 | 142.9 |
| A | 15 | 222 | 51658 | 356.69 | 709 | 694 | 142.9 |
| A | 9 | 143 | 22482 | 152.49 | 709 | 694 | 142.9 |
| B | 10 | 246 | 568851 | 4218.57 | 703 | 684 | 134.7 |
| B | 5 | 172 | 127502 | 941.61 | 703 | 684 | 134.7 |
| B | 0 | 189 | 104728 | 772.51 | 703 | 684 | 134.7 |
| C | 15 | 214 | 276350 | 1726.06 | 689 | 695 | 159.7 |
| C | 0 | 10 | 90849 | 564.51 | 689 | 695 | 159.7 |
| C | 1 | 23 | 6118 | 33.96 | 689 | 695 | 159.7 |
| D | 2 | 249 | 260684 | 1580.32 | 680 | 663 | 164.5 |
| D | 13 | 249 | 176635 | 1069.5 | 680 | 663 | 164.5 |
| D | 10 | 199 | 120836 | 730.37 | 680 | 663 | 164.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
