| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_025T09_9000005382_38394cztM0_level2.fits | modeM0/AS1A12_025T09_9000005382_38394cztM0_level2_quad_clean.evt |
| Size (bytes) | 31,587,840 | 6,618,240 |
| Size | 30.1 MB | 6.3 MB |
| Events in quadrant A | 267,043 | 43,304 |
| Events in quadrant B | 176,280 | 43,936 |
| Events in quadrant C | 195,855 | 41,495 |
| Events in quadrant D | 496,304 | 36,706 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1077 | 1 |
| B | 0 | 784 | 1 |
| C | 0 | 831 | 1 |
| D | 0 | 1763 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 388 | 3 | 0.773196% |
| B | 388 | 1 | 0.257732% |
| C | 388 | 3 | 0.773196% |
| D | 388 | 22 | 5.670103% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 388 | 388 | 3 | 3 | 0.77% | 0.77% |  |
| B | 388 | 388 | 0 | 0 | 0.00% | 0.00% |  |
| C | 388 | 388 | 2 | 2 | 0.52% | 0.52% |  |
| D | 388 | 388 | 16 | 16 | 4.12% | 4.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 86179 | 8269.58 | 41 | 41 | 10.4 |
| A | 9 | 143 | 5258 | 500.85 | 41 | 41 | 10.4 |
| A | 12 | 16 | 5061 | 481.94 | 41 | 41 | 10.4 |
| B | 0 | 183 | 7896 | 759.71 | 41 | 40 | 10.3 |
| B | 0 | 230 | 1308 | 122.62 | 41 | 40 | 10.3 |
| B | 12 | 111 | 1087 | 101.25 | 41 | 40 | 10.3 |
| C | 15 | 214 | 21164 | 1881.31 | 39 | 39 | 11.2 |
| C | 0 | 10 | 17202 | 1528.47 | 39 | 39 | 11.2 |
| C | 1 | 241 | 769 | 65.01 | 39 | 39 | 11.2 |
| D | 10 | 203 | 298513 | 25784.27 | 38 | 36 | 11.6 |
| D | 13 | 171 | 19447 | 1676.84 | 38 | 36 | 11.6 |
| D | 2 | 153 | 11716 | 1008.99 | 38 | 36 | 11.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
