| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_044T05_9000005480_39471cztM0_level2.fits | modeM0/AS1A12_044T05_9000005480_39471cztM0_level2_quad_clean.evt |
| Size (bytes) | 419,719,680 | 88,551,360 |
| Size | 400.3 MB | 84.4 MB |
| Events in quadrant A | 4,440,977 | 564,795 |
| Events in quadrant B | 2,486,671 | 640,019 |
| Events in quadrant C | 4,100,537 | 562,911 |
| Events in quadrant D | 4,082,219 | 530,386 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33 | 0 |
| B | 0 | 33 | 0 |
| C | 0 | 33 | 0 |
| D | 0 | 33 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 112 | 0 |
| B | 0 | 112 | 0 |
| C | 0 | 112 | 0 |
| D | 0 | 112 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16641 | 3 |
| B | 0 | 11170 | 2 |
| C | 0 | 15904 | 2 |
| D | 0 | 15859 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5477 | 568 | 10.370641% |
| B | 5477 | 17 | 0.310389% |
| C | 5477 | 474 | 8.654373% |
| D | 5477 | 415 | 7.577141% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8732 | 5479 | 467 | 467 | 5.35% | 8.52% |  |
| B | 8732 | 5479 | 8 | 8 | 0.09% | 0.15% |  |
| C | 8732 | 5479 | 338 | 338 | 3.87% | 6.17% |  |
| D | 8732 | 5479 | 337 | 337 | 3.86% | 6.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 222 | 1501029 | 12356.82 | 595 | 583 | 121.4 |
| A | 10 | 83 | 424296 | 3489.46 | 595 | 583 | 121.4 |
| A | 9 | 143 | 102003 | 835.24 | 595 | 583 | 121.4 |
| B | 8 | 3 | 54411 | 450.26 | 611 | 594 | 119.5 |
| B | 12 | 111 | 14972 | 120.29 | 611 | 594 | 119.5 |
| B | 11 | 111 | 13860 | 110.99 | 611 | 594 | 119.5 |
| C | 15 | 208 | 1181396 | 8666.02 | 582 | 586 | 136.3 |
| C | 9 | 187 | 410559 | 3008.81 | 582 | 586 | 136.3 |
| C | 15 | 214 | 222547 | 1628.98 | 582 | 586 | 136.3 |
| D | 2 | 249 | 920353 | 6436.93 | 578 | 561 | 142.9 |
| D | 12 | 0 | 349129 | 2439.37 | 578 | 561 | 142.9 |
| D | 13 | 249 | 199107 | 1389.47 | 578 | 561 | 142.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
