| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_054T03_9000005516_40016cztM0_level2.fits | modeM0/AS1A12_054T03_9000005516_40016cztM0_level2_quad_clean.evt |
| Size (bytes) | 405,858,240 | 90,547,200 |
| Size | 387.1 MB | 86.4 MB |
| Events in quadrant A | 3,560,762 | 606,908 |
| Events in quadrant B | 3,397,888 | 621,683 |
| Events in quadrant C | 3,375,334 | 590,941 |
| Events in quadrant D | 4,244,518 | 522,214 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13993 | 3 |
| B | 0 | 13944 | 2 |
| C | 0 | 13576 | 2 |
| D | 0 | 16624 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5719 | 147 | 2.570379% |
| B | 5719 | 212 | 3.706942% |
| C | 5719 | 205 | 3.584543% |
| D | 5719 | 445 | 7.781081% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7092 | 5720 | 110 | 110 | 1.55% | 1.92% |  |
| B | 7092 | 5720 | 142 | 142 | 2.00% | 2.48% |  |
| C | 7092 | 5720 | 170 | 170 | 2.40% | 2.97% |  |
| D | 7092 | 5720 | 393 | 393 | 5.54% | 6.87% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 505142 | 3955.35 | 621 | 606 | 127.6 |
| A | 13 | 248 | 387626 | 3034.07 | 621 | 606 | 127.6 |
| A | 7 | 3 | 210555 | 1645.91 | 621 | 606 | 127.6 |
| B | 4 | 171 | 881178 | 7331.95 | 611 | 595 | 120.1 |
| B | 0 | 230 | 40854 | 335.21 | 611 | 595 | 120.1 |
| B | 4 | 170 | 28281 | 230.52 | 611 | 595 | 120.1 |
| C | 14 | 254 | 663314 | 4670.24 | 601 | 603 | 141.9 |
| C | 15 | 214 | 233503 | 1641.29 | 601 | 603 | 141.9 |
| C | 15 | 208 | 40744 | 282.88 | 601 | 603 | 141.9 |
| D | 12 | 227 | 845183 | 5875.77 | 590 | 572 | 143.7 |
| D | 13 | 249 | 579736 | 4029.12 | 590 | 572 | 143.7 |
| D | 2 | 250 | 307384 | 2134.42 | 590 | 572 | 143.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
