| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_056T02_9000005538_40359cztM0_level2.fits | modeM0/AS1A12_056T02_9000005538_40359cztM0_level2_quad_clean.evt |
| Size (bytes) | 362,341,440 | 95,765,760 |
| Size | 345.6 MB | 91.3 MB |
| Events in quadrant A | 3,205,029 | 678,253 |
| Events in quadrant B | 2,917,975 | 679,018 |
| Events in quadrant C | 3,093,798 | 649,476 |
| Events in quadrant D | 3,799,160 | 536,513 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12526 | 3 |
| B | 0 | 11743 | 2 |
| C | 0 | 12269 | 2 |
| D | 0 | 14596 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5090 | 65 | 1.277014% |
| B | 5090 | 174 | 3.418468% |
| C | 5090 | 63 | 1.237721% |
| D | 5090 | 710 | 13.948919% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7183 | 5091 | 47 | 47 | 0.65% | 0.92% |  |
| B | 7183 | 5091 | 89 | 89 | 1.24% | 1.75% |  |
| C | 7183 | 5091 | 57 | 57 | 0.79% | 1.12% |  |
| D | 7183 | 5091 | 194 | 194 | 2.70% | 3.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 472890 | 3795.46 | 620 | 611 | 124.4 |
| A | 13 | 248 | 230600 | 1848.3 | 620 | 611 | 124.4 |
| A | 15 | 250 | 53176 | 422.44 | 620 | 611 | 124.4 |
| B | 4 | 170 | 461508 | 4042.39 | 605 | 590 | 114.0 |
| B | 0 | 230 | 47885 | 414.79 | 605 | 590 | 114.0 |
| B | 5 | 255 | 36734 | 316.99 | 605 | 590 | 114.0 |
| C | 14 | 254 | 525572 | 3859.13 | 593 | 599 | 136.0 |
| C | 15 | 214 | 215722 | 1581.39 | 593 | 599 | 136.0 |
| C | 0 | 10 | 37955 | 274.61 | 593 | 599 | 136.0 |
| D | 12 | 227 | 958684 | 6917.35 | 561 | 546 | 138.5 |
| D | 13 | 171 | 164005 | 1180.11 | 561 | 546 | 138.5 |
| D | 12 | 191 | 159729 | 1149.23 | 561 | 546 | 138.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
