| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_056T02_9000005538_40360cztM0_level2.fits | modeM0/AS1A12_056T02_9000005538_40360cztM0_level2_quad_clean.evt |
| Size (bytes) | 336,600,000 | 92,773,440 |
| Size | 321.0 MB | 88.5 MB |
| Events in quadrant A | 2,960,409 | 650,611 |
| Events in quadrant B | 2,483,653 | 667,523 |
| Events in quadrant C | 3,391,707 | 609,133 |
| Events in quadrant D | 3,234,118 | 531,794 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11823 | 3 |
| B | 0 | 10504 | 2 |
| C | 0 | 13217 | 2 |
| D | 0 | 12722 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 33 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5004 | 44 | 0.879297% |
| B | 5004 | 13 | 0.259792% |
| C | 5004 | 190 | 3.796962% |
| D | 5004 | 420 | 8.393285% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7128 | 5005 | 26 | 26 | 0.36% | 0.52% |  |
| B | 7128 | 5005 | 3 | 3 | 0.04% | 0.06% |  |
| C | 7128 | 5005 | 188 | 188 | 2.64% | 3.76% |  |
| D | 7128 | 5005 | 145 | 145 | 2.03% | 2.90% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 466492 | 3860.47 | 593 | 584 | 120.7 |
| A | 13 | 248 | 143054 | 1180.49 | 593 | 584 | 120.7 |
| A | 15 | 250 | 31112 | 252.95 | 593 | 584 | 120.7 |
| B | 4 | 170 | 89149 | 789.29 | 590 | 574 | 112.2 |
| B | 0 | 230 | 54944 | 484.49 | 590 | 574 | 112.2 |
| B | 0 | 245 | 18795 | 162.37 | 590 | 574 | 112.2 |
| C | 14 | 254 | 960342 | 7379.14 | 561 | 565 | 130.1 |
| C | 15 | 214 | 210801 | 1616.38 | 561 | 565 | 130.1 |
| C | 0 | 10 | 26717 | 201.07 | 561 | 565 | 130.1 |
| D | 12 | 227 | 388813 | 2903.23 | 544 | 529 | 133.7 |
| D | 12 | 128 | 252339 | 1882.81 | 544 | 529 | 133.7 |
| D | 12 | 191 | 130288 | 970.22 | 544 | 529 | 133.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
