| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_022T01_9000005540_40485cztM0_level2.fits | modeM0/AS1A12_022T01_9000005540_40485cztM0_level2_quad_clean.evt |
| Size (bytes) | 313,179,840 | 88,090,560 |
| Size | 298.7 MB | 84.0 MB |
| Events in quadrant A | 2,851,812 | 602,294 |
| Events in quadrant B | 2,718,707 | 616,590 |
| Events in quadrant C | 2,573,639 | 589,599 |
| Events in quadrant D | 3,014,557 | 469,965 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11861 | 3 |
| B | 0 | 11964 | 2 |
| C | 0 | 11330 | 2 |
| D | 0 | 13001 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33 | 0 |
| B | 0 | 33 | 0 |
| C | 0 | 33 | 0 |
| D | 0 | 33 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 112 | 0 |
| B | 0 | 112 | 0 |
| C | 0 | 112 | 0 |
| D | 0 | 112 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5558 | 7 | 0.125945% |
| B | 5558 | 17 | 0.305865% |
| C | 5558 | 6 | 0.107953% |
| D | 5558 | 873 | 15.707089% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8844 | 5560 | 2 | 2 | 0.02% | 0.04% |  |
| B | 8844 | 5560 | 10 | 10 | 0.11% | 0.18% |  |
| C | 8844 | 5560 | 1 | 1 | 0.01% | 0.02% |  |
| D | 8844 | 5560 | 89 | 89 | 1.01% | 1.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 509556 | 4191.29 | 594 | 581 | 121.4 |
| A | 12 | 189 | 14341 | 113.31 | 594 | 581 | 121.4 |
| A | 13 | 6 | 11418 | 89.24 | 594 | 581 | 121.4 |
| B | 4 | 170 | 361974 | 3159.16 | 589 | 572 | 114.4 |
| B | 5 | 255 | 14603 | 122.65 | 589 | 572 | 114.4 |
| B | 12 | 111 | 14601 | 122.63 | 589 | 572 | 114.4 |
| C | 15 | 214 | 240498 | 1774.85 | 576 | 579 | 135.2 |
| C | 9 | 187 | 56141 | 411.03 | 576 | 579 | 135.2 |
| C | 14 | 254 | 19348 | 138.85 | 576 | 579 | 135.2 |
| D | 2 | 250 | 491269 | 3772.13 | 527 | 510 | 130.1 |
| D | 12 | 191 | 216845 | 1662.82 | 527 | 510 | 130.1 |
| D | 12 | 128 | 78077 | 596.2 | 527 | 510 | 130.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
