| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_029T02_9000005558_40697cztM0_level2.fits | modeM0/AS1A12_029T02_9000005558_40697cztM0_level2_quad_clean.evt |
| Size (bytes) | 439,058,880 | 92,594,880 |
| Size | 418.7 MB | 88.3 MB |
| Events in quadrant A | 3,175,263 | 637,004 |
| Events in quadrant B | 3,255,799 | 648,173 |
| Events in quadrant C | 5,831,641 | 581,453 |
| Events in quadrant D | 3,530,329 | 523,526 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12815 | 3 |
| B | 0 | 13544 | 2 |
| C | 0 | 21424 | 2 |
| D | 0 | 14360 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5909 | 19 | 0.321543% |
| B | 5909 | 116 | 1.963107% |
| C | 5909 | 560 | 9.477069% |
| D | 5909 | 579 | 9.798612% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7253 | 5910 | 5 | 5 | 0.07% | 0.08% |  |
| B | 7253 | 5910 | 74 | 74 | 1.02% | 1.25% |  |
| C | 7253 | 5910 | 536 | 536 | 7.39% | 9.07% |  |
| D | 7253 | 5910 | 109 | 109 | 1.50% | 1.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 542664 | 4001.08 | 658 | 645 | 135.5 |
| A | 12 | 189 | 54037 | 394.13 | 658 | 645 | 135.5 |
| A | 6 | 10 | 16365 | 116.04 | 658 | 645 | 135.5 |
| B | 0 | 229 | 507224 | 4030.59 | 649 | 631 | 125.7 |
| B | 0 | 190 | 109755 | 868.22 | 649 | 631 | 125.7 |
| B | 4 | 171 | 25943 | 201.39 | 649 | 631 | 125.7 |
| C | 9 | 187 | 2894982 | 19876.63 | 618 | 620 | 145.6 |
| C | 15 | 214 | 249021 | 1705.86 | 618 | 620 | 145.6 |
| C | 14 | 254 | 241502 | 1654.22 | 618 | 620 | 145.6 |
| D | 12 | 227 | 248895 | 1643.74 | 607 | 589 | 151.1 |
| D | 2 | 250 | 177054 | 1168.16 | 607 | 589 | 151.1 |
| D | 12 | 191 | 168676 | 1112.7 | 607 | 589 | 151.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
