Observation information
- date-obs: 2023-04-10
- time-obs: 01:32:07.141900000
- date-end: 2023-04-10
- time-end: 03:33:45.141500000
- obs_id: A12_042T01_9000005560
- exposure: 4561.38865936
- sourceid: S5 1044+71
- observer: mcerruti
- ra_pnt: 162.1151
- dec_pnt: 71.72665
Basic statistics of files
Param |
Original file |
Final file |
Filename | modeM0/AS1A12_042T01_9000005560_40722cztM0_level2.fits
| modeM0/AS1A12_042T01_9000005560_40722cztM0_level2_quad_clean.evt
|
Size (bytes) | 367,513,920 | 87,171,840 |
Size | 350.5 MB
| 83.1 MB
|
Events in quadrant A | 2,741,293 | 604,270 |
Events in quadrant B | 2,515,515 | 631,030 |
Events in quadrant C | 5,411,733 | 533,991 |
Events in quadrant D | 2,534,922 | 509,579 |
Level1 data integrity
Mode M0 |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 11270 | 3 |
B | 0 | 10858 | 2 |
C | 0 | 19556 | 2 |
D | 0 | 11293 | 2 |
Mode M9 |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 21 | 0 |
B | 0 | 21 | 0 |
C | 0 | 21 | 0 |
D | 0 | 21 | 0 |
Mode SS |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 106 | 0 |
B | 0 | 106 | 0 |
C | 0 | 106 | 0 |
D | 0 | 106 | 0 |
Data saturation
Quadrant | Total seconds | Saturated seconds | Saturation percentage |
---|
A | 5144 | 9 | 0.174961% |
B | 5144 | 17 | 0.330482% |
C | 5144 | 704 | 13.685848% |
D | 5145 | 343 | 6.666667% |
Noise dominated fraction
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
Quadrant |
# 1 sec bins |
Bins with >0 counts |
Bins with >2000 counts |
High rate bins dominated by noise |
Noise dominated (total time) |
Noise dominated (detector-on time) |
Marked lightcurve |
A | 7297 | 5145 | 5 | 5 | 0.07% | 0.10% |  |
B | 7297 | 5145 | 8 | 8 | 0.11% | 0.16% |  |
C | 7297 | 5145 | 691 | 691 | 9.47% | 13.43% |  |
D | 7298 | 5145 | 27 | 27 | 0.37% | 0.52% |  |
Top noisy pixels
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
Pixel properties |
Quadrant properties |
Quadrant |
DetID |
PixID |
Counts |
Sigma |
Mean |
Median |
Sigma |
A | 10 | 83 | 488637 | 4226.05 | 567 | 556 | 115.5 |
A | 12 | 189 | 28082 | 238.33 | 567 | 556 | 115.5 |
A | 9 | 143 | 22175 | 187.19 | 567 | 556 | 115.5 |
B | 0 | 190 | 86809 | 789.8 | 570 | 553 | 109.2 |
B | 4 | 171 | 50383 | 456.27 | 570 | 553 | 109.2 |
B | 5 | 255 | 45754 | 413.88 | 570 | 553 | 109.2 |
C | 9 | 187 | 3066558 | 25170.41 | 523 | 525 | 121.8 |
C | 15 | 214 | 213209 | 1746.01 | 523 | 525 | 121.8 |
C | 14 | 254 | 69979 | 570.17 | 523 | 525 | 121.8 |
D | 2 | 250 | 155527 | 1228.66 | 522 | 507 | 126.2 |
D | 12 | 191 | 137948 | 1089.33 | 522 | 507 | 126.2 |
D | 2 | 249 | 84683 | 667.16 | 522 | 507 | 126.2 |
Detector plane histogram (DPH)
Histogram calculated using DETX and DETY for each event in the final _common_clean file
Quadrant A |
 |
 |
Quadrant B |
Quadrant D |
 |
 |
Quadrant C |
Count rate plots and images
Plot type |
Count rate plots |
Images |
Comparison with Poisson distribution
Blue bars denote a histogram of data divided into 1 sec bins.
Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
Quadrant-wise count rates
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant A
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant B
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant C
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant D
Data is divided into 100 sec bins |
 |
 |
Housekeeping plots
Parameter |
Plot |
CZT HV Monitor |  |
D_VDD |  |
Temperature 1 |  |
Veto HV Monitor |  |
Veto LLD |  |
Alpha Counter |  |
_CPM_Rate |  |
CZT Counter |  |
+2.5 Volts monitor |  |
+5 Volts monitor |  |
_ROLL_ROT |  |
_Roll_DEC |  |
_Roll_RA |  |
Veto Counter |  |
