| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_100T01_9000005628_41208cztM0_level2.fits | modeM0/AS1A12_100T01_9000005628_41208cztM0_level2_quad_clean.evt |
| Size (bytes) | 290,923,200 | 84,314,880 |
| Size | 277.4 MB | 80.4 MB |
| Events in quadrant A | 2,727,441 | 563,697 |
| Events in quadrant B | 2,698,523 | 566,868 |
| Events in quadrant C | 2,474,315 | 547,511 |
| Events in quadrant D | 2,460,830 | 508,264 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11367 | 2 |
| B | 0 | 11799 | 2 |
| C | 0 | 10824 | 2 |
| D | 0 | 11279 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5228 | 15 | 0.286917% |
| B | 5228 | 112 | 2.142311% |
| C | 5228 | 31 | 0.592961% |
| D | 5228 | 47 | 0.899005% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6541 | 5229 | 6 | 6 | 0.09% | 0.11% |  |
| B | 6540 | 5228 | 90 | 90 | 1.38% | 1.72% |  |
| C | 6541 | 5229 | 23 | 23 | 0.35% | 0.44% |  |
| D | 6541 | 5229 | 48 | 48 | 0.73% | 0.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 484085 | 4164.22 | 564 | 552 | 116.1 |
| A | 12 | 189 | 22011 | 184.81 | 564 | 552 | 116.1 |
| A | 7 | 3 | 13513 | 111.62 | 564 | 552 | 116.1 |
| B | 5 | 255 | 308923 | 2845.31 | 553 | 537 | 108.4 |
| B | 0 | 229 | 198687 | 1828.22 | 553 | 537 | 108.4 |
| B | 12 | 111 | 14027 | 124.46 | 553 | 537 | 108.4 |
| C | 15 | 214 | 224848 | 1734.28 | 548 | 553 | 129.3 |
| C | 0 | 10 | 98533 | 757.59 | 548 | 553 | 129.3 |
| C | 14 | 254 | 9529 | 69.4 | 548 | 553 | 129.3 |
| D | 2 | 120 | 187796 | 1396.84 | 546 | 531 | 134.1 |
| D | 2 | 249 | 109866 | 815.55 | 546 | 531 | 134.1 |
| D | 13 | 249 | 27828 | 203.61 | 546 | 531 | 134.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
