| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_124T01_9000005712_41877cztM0_level2.fits | modeM0/AS1T05_124T01_9000005712_41877cztM0_level2_quad_clean.evt |
| Size (bytes) | 332,573,760 | 86,238,720 |
| Size | 317.2 MB | 82.2 MB |
| Events in quadrant A | 3,542,698 | 577,012 |
| Events in quadrant B | 2,356,949 | 605,869 |
| Events in quadrant C | 3,197,238 | 532,840 |
| Events in quadrant D | 2,798,574 | 522,653 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 29 | 0 |
| D | 0 | 29 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13995 | 3 |
| B | 0 | 10869 | 2 |
| C | 0 | 12985 | 2 |
| D | 0 | 12280 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5327 | 180 | 3.379013% |
| B | 5327 | 7 | 0.131406% |
| C | 5327 | 316 | 5.932044% |
| D | 5327 | 70 | 1.314060% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7091 | 5328 | 111 | 111 | 1.57% | 2.08% |  |
| B | 7091 | 5328 | 2 | 2 | 0.03% | 0.04% |  |
| C | 7091 | 5328 | 290 | 290 | 4.09% | 5.44% |  |
| D | 7091 | 5328 | 57 | 57 | 0.80% | 1.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 24 | 806219 | 6849.89 | 569 | 558 | 117.6 |
| A | 10 | 83 | 520875 | 4423.84 | 569 | 558 | 117.6 |
| A | 2 | 79 | 10654 | 85.84 | 569 | 558 | 117.6 |
| B | 0 | 190 | 63761 | 567.45 | 572 | 555 | 111.4 |
| B | 0 | 245 | 16779 | 145.65 | 572 | 555 | 111.4 |
| B | 12 | 111 | 14124 | 121.82 | 572 | 555 | 111.4 |
| C | 0 | 10 | 707493 | 5641.4 | 536 | 540 | 125.3 |
| C | 15 | 214 | 208093 | 1656.25 | 536 | 540 | 125.3 |
| C | 14 | 254 | 182325 | 1450.62 | 536 | 540 | 125.3 |
| D | 2 | 249 | 182566 | 1346.27 | 553 | 539 | 135.2 |
| D | 13 | 249 | 181909 | 1341.41 | 553 | 539 | 135.2 |
| D | 2 | 120 | 171001 | 1260.73 | 553 | 539 | 135.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
