Observation information
- date-obs: 2023-07-14
- time-obs: 21:36:48.311900000
- date-end: 2023-07-14
- time-end: 23:55:45.312900000
- obs_id: C07_001T11_9000005760
- exposure: 4628.1298781
- sourceid: Blank Sky-8
- observer: tilak
- ra_pnt: 237.3919
- dec_pnt: 70.34809
Basic statistics of files
Param |
Original file |
Final file |
Filename | modeM0/AS1C07_001T11_9000005760_42142cztM0_level2.fits
| modeM0/AS1C07_001T11_9000005760_42142cztM0_level2_quad_clean.evt
|
Size (bytes) | 279,872,640 | 82,301,760 |
Size | 266.9 MB
| 78.5 MB
|
Events in quadrant A | 2,795,294 | 539,371 |
Events in quadrant B | 2,182,538 | 566,875 |
Events in quadrant C | 2,207,219 | 554,707 |
Events in quadrant D | 2,798,987 | 493,140 |
Level1 data integrity
Mode M0 |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 11286 | 2 |
B | 0 | 10012 | 2 |
C | 0 | 9695 | 2 |
D | 0 | 11857 | 2 |
Mode M9 |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 35 | 0 |
B | 0 | 36 | 0 |
C | 0 | 36 | 0 |
D | 0 | 36 | 0 |
Mode SS |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 98 | 0 |
B | 0 | 98 | 0 |
C | 0 | 98 | 0 |
D | 0 | 98 | 0 |
Data saturation
Quadrant | Total seconds | Saturated seconds | Saturation percentage |
---|
A | 4816 | 94 | 1.951827% |
B | 4816 | 24 | 0.498339% |
C | 4816 | 2 | 0.041528% |
D | 4816 | 156 | 3.239203% |
Noise dominated fraction
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
Quadrant |
# 1 sec bins |
Bins with >0 counts |
Bins with >2000 counts |
High rate bins dominated by noise |
Noise dominated (total time) |
Noise dominated (detector-on time) |
Marked lightcurve |
A | 6969 | 4817 | 77 | 77 | 1.10% | 1.60% |  |
B | 6969 | 4817 | 11 | 11 | 0.16% | 0.23% |  |
C | 6969 | 4817 | 0 | 0 | 0.00% | 0.00% |  |
D | 6969 | 4817 | 136 | 136 | 1.95% | 2.82% |  |
Top noisy pixels
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
Pixel properties |
Quadrant properties |
Quadrant |
DetID |
PixID |
Counts |
Sigma |
Mean |
Median |
Sigma |
A | 10 | 83 | 508680 | 4833.56 | 510 | 499 | 105.1 |
A | 14 | 24 | 200377 | 1901.14 | 510 | 499 | 105.1 |
A | 15 | 223 | 65595 | 619.16 | 510 | 499 | 105.1 |
B | 5 | 255 | 58926 | 595.98 | 517 | 503 | 98.0 |
B | 3 | 112 | 51570 | 520.94 | 517 | 503 | 98.0 |
B | 0 | 229 | 26224 | 262.38 | 517 | 503 | 98.0 |
C | 15 | 214 | 200589 | 1693.38 | 510 | 513 | 118.2 |
C | 15 | 111 | 5363 | 41.05 | 510 | 513 | 118.2 |
C | 12 | 249 | 5050 | 38.4 | 510 | 513 | 118.2 |
D | 13 | 249 | 438560 | 3593.18 | 496 | 483 | 121.9 |
D | 1 | 52 | 125104 | 1022.16 | 496 | 483 | 121.9 |
D | 10 | 199 | 84442 | 688.65 | 496 | 483 | 121.9 |
Detector plane histogram (DPH)
Histogram calculated using DETX and DETY for each event in the final _common_clean file
Quadrant A |
 |
 |
Quadrant B |
Quadrant D |
 |
 |
Quadrant C |
Count rate plots and images
Plot type |
Count rate plots |
Images |
Comparison with Poisson distribution
Blue bars denote a histogram of data divided into 1 sec bins.
Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
Quadrant-wise count rates
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant A
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant B
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant C
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant D
Data is divided into 100 sec bins |
 |
 |
Housekeeping plots
Parameter |
Plot |
CZT HV Monitor |  |
D_VDD |  |
Temperature 1 |  |
Veto HV Monitor |  |
Veto LLD |  |
Alpha Counter |  |
_CPM_Rate |  |
CZT Counter |  |
+2.5 Volts monitor |  |
+5 Volts monitor |  |
_ROLL_ROT |  |
_Roll_DEC |  |
_Roll_RA |  |
Veto Counter |  |
