| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T10_9000005806_42431cztM0_level2.fits | modeM0/AS1C07_001T10_9000005806_42431cztM0_level2_quad_clean.evt |
| Size (bytes) | 426,168,000 | 82,699,200 |
| Size | 406.4 MB | 78.9 MB |
| Events in quadrant A | 3,802,731 | 604,173 |
| Events in quadrant B | 5,542,738 | 438,859 |
| Events in quadrant C | 2,406,105 | 582,852 |
| Events in quadrant D | 3,637,650 | 530,710 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14505 | 2 |
| B | 0 | 19764 | 2 |
| C | 0 | 10109 | 2 |
| D | 0 | 14034 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4961 | 194 | 3.910502% |
| B | 4961 | 1524 | 30.719613% |
| C | 4961 | 6 | 0.120943% |
| D | 4961 | 266 | 5.361822% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7054 | 4962 | 179 | 179 | 2.54% | 3.61% |  |
| B | 7054 | 4962 | 1240 | 1240 | 17.58% | 24.99% |  |
| C | 7054 | 4962 | 3 | 3 | 0.04% | 0.06% |  |
| D | 7054 | 4962 | 215 | 215 | 3.05% | 4.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 223 | 938565 | 8239.54 | 565 | 557 | 113.8 |
| A | 10 | 83 | 566047 | 4967.31 | 565 | 557 | 113.8 |
| A | 13 | 248 | 82656 | 721.16 | 565 | 557 | 113.8 |
| B | 0 | 186 | 3602089 | 40177.85 | 472 | 460 | 89.6 |
| B | 5 | 172 | 29391 | 322.74 | 472 | 460 | 89.6 |
| B | 5 | 255 | 21243 | 231.84 | 472 | 460 | 89.6 |
| C | 15 | 214 | 211825 | 1684.96 | 547 | 550 | 125.4 |
| C | 14 | 254 | 18415 | 142.48 | 547 | 550 | 125.4 |
| C | 7 | 220 | 17614 | 136.09 | 547 | 550 | 125.4 |
| D | 1 | 52 | 436344 | 3306.29 | 545 | 531 | 131.8 |
| D | 10 | 118 | 316339 | 2395.87 | 545 | 531 | 131.8 |
| D | 2 | 16 | 262621 | 1988.34 | 545 | 531 | 131.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
