| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T10_9000005806_42436cztM0_level2.fits | modeM0/AS1C07_001T10_9000005806_42436cztM0_level2_quad_clean.evt |
| Size (bytes) | 433,255,680 | 88,928,640 |
| Size | 413.2 MB | 84.8 MB |
| Events in quadrant A | 3,101,781 | 628,879 |
| Events in quadrant B | 5,485,751 | 487,268 |
| Events in quadrant C | 2,825,414 | 613,436 |
| Events in quadrant D | 4,169,765 | 555,069 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12935 | 2 |
| B | 0 | 20604 | 2 |
| C | 0 | 12350 | 2 |
| D | 0 | 16555 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5846 | 15 | 0.256586% |
| B | 5846 | 1374 | 23.503250% |
| C | 5845 | 22 | 0.376390% |
| D | 5845 | 304 | 5.201027% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7160 | 5847 | 4 | 4 | 0.06% | 0.07% |  |
| B | 7160 | 5846 | 1106 | 1106 | 15.45% | 18.92% |  |
| C | 7159 | 5846 | 20 | 20 | 0.28% | 0.34% |  |
| D | 7159 | 5846 | 283 | 283 | 3.95% | 4.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 635114 | 5034.78 | 615 | 601 | 126.0 |
| A | 13 | 248 | 25675 | 198.96 | 615 | 601 | 126.0 |
| A | 15 | 222 | 21664 | 167.13 | 615 | 601 | 126.0 |
| B | 0 | 186 | 2903967 | 28349.04 | 528 | 513 | 102.4 |
| B | 5 | 255 | 346431 | 3377.51 | 528 | 513 | 102.4 |
| B | 5 | 172 | 38845 | 374.27 | 528 | 513 | 102.4 |
| C | 15 | 214 | 241576 | 1702.76 | 601 | 605 | 141.5 |
| C | 12 | 175 | 104883 | 736.85 | 601 | 605 | 141.5 |
| C | 14 | 254 | 58439 | 408.67 | 601 | 605 | 141.5 |
| D | 2 | 16 | 350728 | 2402.49 | 596 | 582 | 145.7 |
| D | 13 | 171 | 335502 | 2298.01 | 596 | 582 | 145.7 |
| D | 12 | 6 | 253345 | 1734.3 | 596 | 582 | 145.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
