| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T10_9000005806_42512cztM0_level2.fits | modeM0/AS1C07_001T10_9000005806_42512cztM0_level2_quad_clean.evt |
| Size (bytes) | 709,937,280 | 128,672,640 |
| Size | 677.0 MB | 122.7 MB |
| Events in quadrant A | 4,455,378 | 891,171 |
| Events in quadrant B | 4,719,185 | 896,542 |
| Events in quadrant C | 12,047,682 | 714,986 |
| Events in quadrant D | 4,409,476 | 811,299 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29 | 0 |
| B | 0 | 29 | 0 |
| C | 0 | 29 | 0 |
| D | 0 | 29 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 174 | 0 |
| B | 0 | 174 | 0 |
| C | 0 | 174 | 0 |
| D | 0 | 174 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18637 | 2 |
| B | 0 | 19772 | 2 |
| C | 0 | 41381 | 2 |
| D | 0 | 19392 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8364 | 22 | 0.263032% |
| B | 8365 | 108 | 1.291094% |
| C | 8365 | 2008 | 24.004782% |
| D | 8365 | 156 | 1.864913% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 11318 | 8366 | 12 | 12 | 0.11% | 0.14% |  |
| B | 11319 | 8367 | 95 | 95 | 0.84% | 1.14% |  |
| C | 11319 | 8367 | 2371 | 2371 | 20.95% | 28.34% |  |
| D | 11319 | 8367 | 123 | 123 | 1.09% | 1.47% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 754040 | 4100.83 | 896 | 877 | 183.7 |
| A | 13 | 248 | 136005 | 735.75 | 896 | 877 | 183.7 |
| A | 12 | 189 | 51425 | 275.22 | 896 | 877 | 183.7 |
| B | 0 | 229 | 1117571 | 6564.51 | 883 | 860 | 170.1 |
| B | 0 | 245 | 75978 | 441.58 | 883 | 860 | 170.1 |
| B | 12 | 111 | 22035 | 124.48 | 883 | 860 | 170.1 |
| C | 0 | 239 | 8494313 | 44527.22 | 820 | 823 | 190.7 |
| C | 15 | 214 | 347680 | 1818.4 | 820 | 823 | 190.7 |
| C | 13 | 61 | 5411 | 24.05 | 820 | 823 | 190.7 |
| D | 12 | 233 | 224617 | 1056.47 | 869 | 845 | 211.8 |
| D | 1 | 52 | 208920 | 982.36 | 869 | 845 | 211.8 |
| D | 2 | 249 | 166413 | 781.68 | 869 | 845 | 211.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
