| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_013T01_9000005822_42730cztM0_level2.fits | modeM0/AS1A05_013T01_9000005822_42730cztM0_level2_quad_clean.evt |
| Size (bytes) | 390,093,120 | 86,060,160 |
| Size | 372.0 MB | 82.1 MB |
| Events in quadrant A | 2,994,629 | 607,026 |
| Events in quadrant B | 2,881,819 | 599,303 |
| Events in quadrant C | 5,631,553 | 464,262 |
| Events in quadrant D | 2,498,858 | 546,088 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12192 | 2 |
| B | 0 | 12485 | 3 |
| C | 0 | 20236 | 2 |
| D | 0 | 11549 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 114 | 0 |
| B | 0 | 114 | 0 |
| C | 0 | 114 | 0 |
| D | 0 | 114 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5558 | 15 | 0.269881% |
| B | 5557 | 176 | 3.167177% |
| C | 5557 | 1162 | 20.910563% |
| D | 5557 | 18 | 0.323916% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7201 | 5559 | 6 | 6 | 0.08% | 0.11% |  |
| B | 7200 | 5558 | 147 | 147 | 2.04% | 2.64% |  |
| C | 7199 | 5556 | 1125 | 1125 | 15.63% | 20.25% |  |
| D | 7200 | 5558 | 15 | 15 | 0.21% | 0.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 616549 | 4949.37 | 606 | 595 | 124.5 |
| A | 13 | 6 | 13011 | 99.77 | 606 | 595 | 124.5 |
| A | 13 | 248 | 10409 | 78.86 | 606 | 595 | 124.5 |
| B | 5 | 172 | 293418 | 2510.25 | 593 | 577 | 116.7 |
| B | 0 | 229 | 145784 | 1244.73 | 593 | 577 | 116.7 |
| B | 4 | 141 | 37843 | 319.45 | 593 | 577 | 116.7 |
| C | 8 | 79 | 3392356 | 27964.45 | 515 | 518 | 121.3 |
| C | 15 | 214 | 204560 | 1682.25 | 515 | 518 | 121.3 |
| C | 3 | 233 | 14332 | 113.89 | 515 | 518 | 121.3 |
| D | 1 | 52 | 56857 | 390.77 | 585 | 568 | 144.0 |
| D | 2 | 249 | 45522 | 312.08 | 585 | 568 | 144.0 |
| D | 7 | 96 | 29831 | 203.15 | 585 | 568 | 144.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
