| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T10_9000005844_43064cztM0_level2.fits | modeM0/AS1C07_001T10_9000005844_43064cztM0_level2_quad_clean.evt |
| Size (bytes) | 375,445,440 | 87,713,280 |
| Size | 358.1 MB | 83.6 MB |
| Events in quadrant A | 3,281,082 | 591,540 |
| Events in quadrant B | 2,375,936 | 607,687 |
| Events in quadrant C | 2,644,957 | 571,787 |
| Events in quadrant D | 5,177,699 | 508,355 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13052 | 2 |
| B | 0 | 10917 | 2 |
| C | 0 | 11401 | 2 |
| D | 0 | 19140 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5376 | 66 | 1.227679% |
| B | 5376 | 12 | 0.223214% |
| C | 5376 | 24 | 0.446429% |
| D | 5375 | 363 | 6.753488% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7078 | 5377 | 43 | 43 | 0.61% | 0.80% |  |
| B | 7078 | 5377 | 6 | 6 | 0.08% | 0.11% |  |
| C | 7078 | 5377 | 26 | 26 | 0.37% | 0.48% |  |
| D | 7077 | 5376 | 324 | 324 | 4.58% | 6.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 594289 | 4930.67 | 585 | 573 | 120.4 |
| A | 15 | 222 | 229124 | 1898.06 | 585 | 573 | 120.4 |
| A | 15 | 237 | 143165 | 1184.19 | 585 | 573 | 120.4 |
| B | 15 | 85 | 29656 | 256.41 | 582 | 566 | 113.4 |
| B | 4 | 171 | 24577 | 211.64 | 582 | 566 | 113.4 |
| B | 12 | 111 | 14198 | 120.16 | 582 | 566 | 113.4 |
| C | 15 | 214 | 237399 | 1793.75 | 565 | 568 | 132.0 |
| C | 0 | 239 | 172062 | 1298.89 | 565 | 568 | 132.0 |
| C | 14 | 254 | 20130 | 148.16 | 565 | 568 | 132.0 |
| D | 2 | 16 | 1904037 | 14339.69 | 552 | 537 | 132.7 |
| D | 13 | 249 | 630241 | 4743.77 | 552 | 537 | 132.7 |
| D | 1 | 52 | 274253 | 2061.99 | 552 | 537 | 132.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
