| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_006T01_9000005860_43274cztM0_level2.fits | modeM0/AS1A06_006T01_9000005860_43274cztM0_level2_quad_clean.evt |
| Size (bytes) | 315,455,040 | 84,792,960 |
| Size | 300.8 MB | 80.9 MB |
| Events in quadrant A | 3,389,245 | 543,808 |
| Events in quadrant B | 2,343,848 | 586,841 |
| Events in quadrant C | 2,524,131 | 564,210 |
| Events in quadrant D | 3,015,433 | 509,298 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13182 | 2 |
| B | 0 | 10591 | 2 |
| C | 0 | 10670 | 2 |
| D | 0 | 12556 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5186 | 232 | 4.473583% |
| B | 5186 | 12 | 0.231392% |
| C | 5186 | 19 | 0.366371% |
| D | 5186 | 139 | 2.680293% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7098 | 5187 | 183 | 183 | 2.58% | 3.53% |  |
| B | 7098 | 5187 | 5 | 5 | 0.07% | 0.10% |  |
| C | 7098 | 5187 | 16 | 16 | 0.23% | 0.31% |  |
| D | 7098 | 5187 | 129 | 129 | 1.82% | 2.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 237 | 635653 | 5476.61 | 560 | 549 | 116.0 |
| A | 10 | 83 | 555554 | 4785.9 | 560 | 549 | 116.0 |
| A | 13 | 248 | 22995 | 193.56 | 560 | 549 | 116.0 |
| B | 5 | 172 | 25989 | 225.52 | 570 | 553 | 112.8 |
| B | 0 | 189 | 20776 | 179.3 | 570 | 553 | 112.8 |
| B | 4 | 67 | 19113 | 164.55 | 570 | 553 | 112.8 |
| C | 15 | 214 | 220094 | 1650.24 | 564 | 568 | 133.0 |
| C | 14 | 254 | 93905 | 701.64 | 564 | 568 | 133.0 |
| C | 3 | 233 | 7038 | 48.64 | 564 | 568 | 133.0 |
| D | 12 | 233 | 213938 | 1536.93 | 559 | 543 | 138.8 |
| D | 1 | 52 | 209431 | 1504.47 | 559 | 543 | 138.8 |
| D | 2 | 249 | 185506 | 1332.16 | 559 | 543 | 138.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
