| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_143T01_9000005870_43378cztM0_level2.fits | modeM0/AS1A09_143T01_9000005870_43378cztM0_level2_quad_clean.evt |
| Size (bytes) | 254,707,200 | 71,614,080 |
| Size | 242.9 MB | 68.3 MB |
| Events in quadrant A | 2,701,557 | 473,145 |
| Events in quadrant B | 2,031,937 | 491,302 |
| Events in quadrant C | 2,230,234 | 463,768 |
| Events in quadrant D | 2,116,254 | 426,196 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 90 | 0 |
| B | 0 | 90 | 0 |
| C | 0 | 90 | 0 |
| D | 0 | 90 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10612 | 1 |
| B | 0 | 9213 | 1 |
| C | 0 | 9425 | 1 |
| D | 0 | 9605 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4459 | 105 | 2.354788% |
| B | 4459 | 11 | 0.246692% |
| C | 4459 | 3 | 0.067280% |
| D | 4459 | 31 | 0.695223% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4459 | 4459 | 84 | 84 | 1.88% | 1.88% |  |
| B | 4459 | 4459 | 3 | 3 | 0.07% | 0.07% |  |
| C | 4459 | 4459 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4459 | 4459 | 36 | 36 | 0.81% | 0.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 447155 | 4512.77 | 470 | 461 | 99.0 |
| A | 15 | 237 | 355480 | 3586.61 | 470 | 461 | 99.0 |
| A | 13 | 248 | 61370 | 615.34 | 470 | 461 | 99.0 |
| B | 15 | 85 | 46347 | 497.29 | 472 | 459 | 92.3 |
| B | 3 | 112 | 41091 | 440.33 | 472 | 459 | 92.3 |
| B | 0 | 186 | 32338 | 345.48 | 472 | 459 | 92.3 |
| C | 15 | 214 | 183284 | 1658.59 | 465 | 466 | 110.2 |
| C | 3 | 233 | 149289 | 1350.17 | 465 | 466 | 110.2 |
| C | 0 | 207 | 81179 | 732.25 | 465 | 466 | 110.2 |
| D | 13 | 249 | 142736 | 1262.05 | 463 | 450 | 112.7 |
| D | 7 | 96 | 40671 | 356.75 | 463 | 450 | 112.7 |
| D | 5 | 32 | 38571 | 338.12 | 463 | 450 | 112.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
