| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_018T01_9000005874_43396cztM0_level2.fits | modeM0/AS1A12_018T01_9000005874_43396cztM0_level2_quad_clean.evt |
| Size (bytes) | 377,893,440 | 102,700,800 |
| Size | 360.4 MB | 97.9 MB |
| Events in quadrant A | 4,144,915 | 684,255 |
| Events in quadrant B | 2,982,092 | 702,759 |
| Events in quadrant C | 3,212,431 | 664,373 |
| Events in quadrant D | 3,151,651 | 612,048 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16268 | 2 |
| B | 0 | 13243 | 3 |
| C | 0 | 13528 | 2 |
| D | 0 | 14110 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30 | 0 |
| B | 0 | 30 | 0 |
| C | 0 | 30 | 0 |
| D | 0 | 30 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6389 | 137 | 2.144311% |
| B | 6389 | 16 | 0.250430% |
| C | 6389 | 35 | 0.547817% |
| D | 6389 | 70 | 1.095633% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9403 | 6391 | 107 | 107 | 1.14% | 1.67% |  |
| B | 9403 | 6391 | 2 | 2 | 0.02% | 0.03% |  |
| C | 9403 | 6391 | 25 | 25 | 0.27% | 0.39% |  |
| D | 9403 | 6391 | 74 | 74 | 0.79% | 1.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 711238 | 5007.13 | 686 | 672 | 141.9 |
| A | 15 | 237 | 378084 | 2659.5 | 686 | 672 | 141.9 |
| A | 7 | 3 | 330633 | 2325.13 | 686 | 672 | 141.9 |
| B | 0 | 189 | 118876 | 882.5 | 689 | 669 | 133.9 |
| B | 5 | 255 | 59798 | 441.44 | 689 | 669 | 133.9 |
| B | 4 | 67 | 29210 | 213.08 | 689 | 669 | 133.9 |
| C | 15 | 214 | 269007 | 1719.72 | 671 | 674 | 156.0 |
| C | 3 | 233 | 205285 | 1311.33 | 671 | 674 | 156.0 |
| C | 15 | 159 | 53498 | 338.54 | 671 | 674 | 156.0 |
| D | 12 | 6 | 159528 | 961.92 | 674 | 653 | 165.2 |
| D | 10 | 118 | 124254 | 748.35 | 674 | 653 | 165.2 |
| D | 12 | 233 | 68228 | 409.14 | 674 | 653 | 165.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
