| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_174T01_9000005880_43542cztM0_level2.fits | modeM0/AS1A05_174T01_9000005880_43542cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,126,368,000 | 67,032,000 |
| Size | 1.0 GB | 63.9 MB |
| Events in quadrant A | 7,758,706 | 634,753 |
| Events in quadrant B | 5,158,057 | 683,377 |
| Events in quadrant C | 16,267,496 | 158,878 |
| Events in quadrant D | 12,039,624 | 120,172 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27465 | 80 |
| B | 0 | 19611 | 34 |
| C | 0 | 52573 | 129 |
| D | 0 | 40091 | 145 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 123 | 1 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6097 | 1222 | 20.042644% |
| B | 6110 | 313 | 5.122750% |
| C | 6101 | 6090 | 99.819702% |
| D | 6093 | 6093 | 100.000000% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7117 | 6109 | 689 | 689 | 9.68% | 11.28% |  |
| B | 7117 | 6115 | 232 | 232 | 3.26% | 3.79% |  |
| C | 7117 | 6102 | 5959 | 5959 | 83.73% | 97.66% |  |
| D | 7116 | 6092 | 3218 | 3218 | 45.22% | 52.82% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 228 | 3282637 | 24043.52 | 657 | 645 | 136.5 |
| A | 10 | 83 | 666449 | 4877.61 | 657 | 645 | 136.5 |
| A | 15 | 223 | 308946 | 2258.58 | 657 | 645 | 136.5 |
| B | 3 | 42 | 1192313 | 8854.3 | 684 | 667 | 134.6 |
| B | 3 | 25 | 435275 | 3229.27 | 684 | 667 | 134.6 |
| B | 15 | 36 | 268286 | 1988.49 | 684 | 667 | 134.6 |
| C | 15 | 174 | 8472680 | 201786.87 | 171 | 172 | 42.0 |
| C | 15 | 142 | 5010774 | 119335.82 | 171 | 172 | 42.0 |
| C | 15 | 158 | 784349 | 18676.48 | 171 | 172 | 42.0 |
| D | 4 | 216 | 2854539 | 51569.62 | 151 | 143 | 55.4 |
| D | 4 | 212 | 2511642 | 45374.59 | 151 | 143 | 55.4 |
| D | 8 | 160 | 648108 | 11706.61 | 151 | 143 | 55.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
