| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_174T01_9000005880_43558cztM0_level2.fits | modeM0/AS1A05_174T01_9000005880_43558cztM0_level2_quad_clean.evt |
| Size (bytes) | 890,354,880 | 80,732,160 |
| Size | 849.1 MB | 77.0 MB |
| Events in quadrant A | 5,549,443 | 676,095 |
| Events in quadrant B | 3,375,400 | 707,176 |
| Events in quadrant C | 11,948,269 | 522,005 |
| Events in quadrant D | 11,614,777 | 111,128 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20923 | 1 |
| B | 0 | 14068 | 1 |
| C | 0 | 39657 | 5 |
| D | 0 | 38658 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6064 | 297 | 4.897757% |
| B | 6064 | 118 | 1.945910% |
| C | 6063 | 2930 | 48.325911% |
| D | 6064 | 6027 | 99.389842% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7089 | 6064 | 162 | 162 | 2.29% | 2.67% |  |
| B | 7089 | 6064 | 46 | 46 | 0.65% | 0.76% |  |
| C | 7087 | 6062 | 2736 | 2736 | 38.61% | 45.13% |  |
| D | 7088 | 6063 | 2822 | 2822 | 39.81% | 46.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 228 | 1090834 | 7605.56 | 693 | 680 | 143.3 |
| A | 10 | 83 | 624555 | 4352.52 | 693 | 680 | 143.3 |
| A | 10 | 99 | 601492 | 4191.62 | 693 | 680 | 143.3 |
| B | 3 | 25 | 202051 | 1476.32 | 695 | 676 | 136.4 |
| B | 0 | 199 | 109927 | 800.94 | 695 | 676 | 136.4 |
| B | 0 | 230 | 93579 | 681.09 | 695 | 676 | 136.4 |
| C | 15 | 142 | 4335795 | 34932.99 | 521 | 524 | 124.1 |
| C | 15 | 126 | 2335696 | 18816.48 | 521 | 524 | 124.1 |
| C | 15 | 158 | 1675171 | 13494.06 | 521 | 524 | 124.1 |
| D | 4 | 212 | 4188944 | 89294.3 | 142 | 135 | 46.9 |
| D | 4 | 216 | 3171797 | 67611.43 | 142 | 135 | 46.9 |
| D | 14 | 210 | 676619 | 14420.85 | 142 | 135 | 46.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
