| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_018T01_9000005896_43662cztM0_level2.fits | modeM0/AS1A12_018T01_9000005896_43662cztM0_level2_quad_clean.evt |
| Size (bytes) | 847,203,840 | 63,820,800 |
| Size | 808.0 MB | 60.9 MB |
| Events in quadrant A | 4,066,982 | 615,737 |
| Events in quadrant B | 4,064,075 | 626,511 |
| Events in quadrant C | 13,342,813 | 46,918 |
| Events in quadrant D | 9,489,061 | 282,476 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15849 | 1 |
| B | 0 | 15558 | 1 |
| C | 0 | 43130 | 1 |
| D | 0 | 31821 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5148 | 193 | 3.749029% |
| B | 5148 | 199 | 3.865579% |
| C | 5148 | 4873 | 94.658120% |
| D | 5147 | 2782 | 54.050903% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6323 | 5149 | 33 | 33 | 0.52% | 0.64% |  |
| B | 6323 | 5149 | 93 | 93 | 1.47% | 1.81% |  |
| C | 6323 | 5149 | 4744 | 4744 | 75.03% | 92.13% |  |
| D | 6322 | 5147 | 2315 | 2315 | 36.62% | 44.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 715436 | 5845.31 | 600 | 589 | 122.3 |
| A | 15 | 222 | 510067 | 4166.0 | 600 | 589 | 122.3 |
| A | 15 | 223 | 319319 | 2606.26 | 600 | 589 | 122.3 |
| B | 4 | 206 | 1035743 | 9072.8 | 593 | 575 | 114.1 |
| B | 0 | 230 | 237375 | 2075.45 | 593 | 575 | 114.1 |
| B | 5 | 235 | 120216 | 1048.6 | 593 | 575 | 114.1 |
| C | 15 | 142 | 10977991 | 218876.77 | 217 | 218 | 50.2 |
| C | 15 | 157 | 828654 | 16517.5 | 217 | 218 | 50.2 |
| C | 15 | 158 | 518078 | 10325.18 | 217 | 218 | 50.2 |
| D | 8 | 192 | 2301577 | 21771.79 | 398 | 385 | 105.7 |
| D | 7 | 80 | 1854179 | 17538.91 | 398 | 385 | 105.7 |
| D | 5 | 235 | 560809 | 5302.22 | 398 | 385 | 105.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
