| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_080T06_9000005954_44156cztM0_level2.fits | modeM0/AS1A13_080T06_9000005954_44156cztM0_level2_quad_clean.evt |
| Size (bytes) | 552,974,400 | 107,046,720 |
| Size | 527.4 MB | 102.1 MB |
| Events in quadrant A | 6,164,601 | 714,391 |
| Events in quadrant B | 4,850,251 | 730,849 |
| Events in quadrant C | 3,185,482 | 724,167 |
| Events in quadrant D | 5,767,391 | 620,124 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22865 | 2 |
| B | 0 | 18928 | 2 |
| C | 0 | 14180 | 2 |
| D | 0 | 21719 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6472 | 383 | 5.917800% |
| B | 6472 | 527 | 8.142769% |
| C | 6472 | 67 | 1.035229% |
| D | 6472 | 477 | 7.370210% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7662 | 6473 | 228 | 228 | 2.98% | 3.52% |  |
| B | 7662 | 6473 | 306 | 306 | 3.99% | 4.73% |  |
| C | 7662 | 6473 | 26 | 26 | 0.34% | 0.40% |  |
| D | 7662 | 6473 | 372 | 372 | 4.86% | 5.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1563868 | 10545.23 | 715 | 701 | 148.2 |
| A | 15 | 223 | 1165020 | 7854.58 | 715 | 701 | 148.2 |
| A | 7 | 16 | 182752 | 1228.13 | 715 | 701 | 148.2 |
| B | 5 | 172 | 766390 | 5651.78 | 709 | 688 | 135.5 |
| B | 5 | 235 | 292459 | 2153.61 | 709 | 688 | 135.5 |
| B | 0 | 200 | 184821 | 1359.12 | 709 | 688 | 135.5 |
| C | 14 | 254 | 167284 | 1006.52 | 706 | 711 | 165.5 |
| C | 5 | 4 | 73815 | 441.73 | 706 | 711 | 165.5 |
| C | 15 | 208 | 46072 | 274.09 | 706 | 711 | 165.5 |
| D | 5 | 235 | 769518 | 4393.73 | 682 | 658 | 175.0 |
| D | 13 | 187 | 698246 | 3986.44 | 682 | 658 | 175.0 |
| D | 12 | 233 | 602455 | 3439.03 | 682 | 658 | 175.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
