| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_074T09_9000005968_44204cztM0_level2.fits | modeM0/AS1A13_074T09_9000005968_44204cztM0_level2_quad_clean.evt |
| Size (bytes) | 620,835,840 | 105,514,560 |
| Size | 592.1 MB | 100.6 MB |
| Events in quadrant A | 9,267,770 | 592,052 |
| Events in quadrant B | 4,187,355 | 758,455 |
| Events in quadrant C | 3,435,217 | 729,680 |
| Events in quadrant D | 5,556,931 | 634,397 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32531 | 0 |
| B | 0 | 17280 | 0 |
| C | 0 | 15042 | 0 |
| D | 0 | 21283 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6889 | 1702 | 24.706053% |
| B | 6889 | 148 | 2.148352% |
| C | 6890 | 22 | 0.319303% |
| D | 6890 | 494 | 7.169811% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6889 | 6889 | 1220 | 1220 | 17.71% | 17.71% |  |
| B | 6889 | 6889 | 39 | 39 | 0.57% | 0.57% |  |
| C | 6890 | 6890 | 26 | 26 | 0.38% | 0.38% |  |
| D | 6890 | 6890 | 410 | 410 | 5.95% | 5.95% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 5253756 | 35200.34 | 712 | 697 | 149.2 |
| A | 10 | 83 | 1237478 | 8287.57 | 712 | 697 | 149.2 |
| A | 13 | 6 | 15307 | 97.9 | 712 | 697 | 149.2 |
| B | 0 | 200 | 634103 | 4083.31 | 777 | 753 | 155.1 |
| B | 5 | 172 | 134825 | 864.38 | 777 | 753 | 155.1 |
| B | 0 | 219 | 121903 | 781.07 | 777 | 753 | 155.1 |
| C | 14 | 254 | 155876 | 850.37 | 766 | 770 | 182.4 |
| C | 4 | 254 | 132272 | 720.96 | 766 | 770 | 182.4 |
| C | 3 | 233 | 109336 | 595.22 | 766 | 770 | 182.4 |
| D | 2 | 249 | 870642 | 4569.85 | 740 | 717 | 190.4 |
| D | 12 | 16 | 674798 | 3541.05 | 740 | 717 | 190.4 |
| D | 1 | 52 | 346366 | 1815.75 | 740 | 717 | 190.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
