| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_047T01_9000005970_44214cztM0_level2.fits | modeM0/AS1A13_047T01_9000005970_44214cztM0_level2_quad_clean.evt |
| Size (bytes) | 629,023,680 | 103,435,200 |
| Size | 599.9 MB | 98.6 MB |
| Events in quadrant A | 11,207,376 | 577,360 |
| Events in quadrant B | 4,211,663 | 725,792 |
| Events in quadrant C | 3,073,245 | 725,409 |
| Events in quadrant D | 4,291,743 | 652,657 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 37782 | 1 |
| B | 0 | 16968 | 1 |
| C | 0 | 13843 | 2 |
| D | 0 | 17399 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6457 | 1937 | 29.998451% |
| B | 6457 | 506 | 7.836457% |
| C | 6457 | 32 | 0.495586% |
| D | 6457 | 232 | 3.593000% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7612 | 6458 | 1848 | 1848 | 24.28% | 28.62% |  |
| B | 7612 | 6458 | 301 | 301 | 3.95% | 4.66% |  |
| C | 7612 | 6458 | 9 | 9 | 0.12% | 0.14% |  |
| D | 7612 | 6458 | 183 | 183 | 2.40% | 2.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 7150010 | 49234.34 | 698 | 686 | 145.2 |
| A | 10 | 83 | 1365057 | 9395.84 | 698 | 686 | 145.2 |
| A | 3 | 137 | 7766 | 48.76 | 698 | 686 | 145.2 |
| B | 5 | 172 | 1161490 | 8234.73 | 721 | 701 | 141.0 |
| B | 4 | 171 | 72897 | 512.16 | 721 | 701 | 141.0 |
| B | 0 | 200 | 38420 | 267.58 | 721 | 701 | 141.0 |
| C | 4 | 254 | 138370 | 816.65 | 717 | 721 | 168.6 |
| C | 14 | 254 | 87148 | 512.76 | 717 | 721 | 168.6 |
| C | 3 | 233 | 53427 | 312.7 | 717 | 721 | 168.6 |
| D | 1 | 52 | 900026 | 5016.36 | 707 | 685 | 179.3 |
| D | 2 | 249 | 429347 | 2391.0 | 707 | 685 | 179.3 |
| D | 12 | 34 | 81444 | 450.46 | 707 | 685 | 179.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
