| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_077T01_9000005984_44271cztM0_level2.fits | modeM0/AS1A13_077T01_9000005984_44271cztM0_level2_quad_clean.evt |
| Size (bytes) | 213,943,680 | 29,090,880 |
| Size | 204.0 MB | 27.7 MB |
| Events in quadrant A | 3,658,148 | 77,553 |
| Events in quadrant B | 1,246,093 | 243,778 |
| Events in quadrant C | 1,060,058 | 234,354 |
| Events in quadrant D | 1,806,619 | 187,923 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12160 | 1 |
| B | 0 | 4993 | 1 |
| C | 0 | 4282 | 1 |
| D | 0 | 6660 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40 | 0 |
| B | 0 | 40 | 0 |
| C | 0 | 40 | 0 |
| D | 0 | 40 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1877 | 1349 | 71.870005% |
| B | 1877 | 100 | 5.327651% |
| C | 1877 | 66 | 3.516249% |
| D | 1876 | 338 | 18.017058% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3122 | 1877 | 969 | 969 | 31.04% | 51.62% |  |
| B | 3122 | 1878 | 6 | 6 | 0.19% | 0.32% |  |
| C | 3122 | 1878 | 2 | 2 | 0.06% | 0.11% |  |
| D | 3121 | 1877 | 173 | 173 | 5.54% | 9.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 2473098 | 59842.37 | 189 | 185 | 41.3 |
| A | 10 | 83 | 438607 | 10609.43 | 189 | 185 | 41.3 |
| A | 4 | 0 | 6814 | 160.42 | 189 | 185 | 41.3 |
| B | 4 | 173 | 54119 | 1011.37 | 261 | 254 | 53.3 |
| B | 5 | 172 | 36913 | 688.31 | 261 | 254 | 53.3 |
| B | 5 | 235 | 26363 | 490.22 | 261 | 254 | 53.3 |
| C | 14 | 254 | 31354 | 495.3 | 259 | 260 | 62.8 |
| C | 3 | 233 | 8784 | 135.78 | 259 | 260 | 62.8 |
| C | 4 | 254 | 5118 | 77.38 | 259 | 260 | 62.8 |
| D | 1 | 52 | 322265 | 5144.19 | 245 | 238 | 62.6 |
| D | 12 | 1 | 231708 | 3697.6 | 245 | 238 | 62.6 |
| D | 13 | 249 | 122760 | 1957.22 | 245 | 238 | 62.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
