| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_012T08_9000005986_44287cztM0_level2.fits | modeM0/AS1A13_012T08_9000005986_44287cztM0_level2_quad_clean.evt |
| Size (bytes) | 269,383,680 | 52,116,480 |
| Size | 256.9 MB | 49.7 MB |
| Events in quadrant A | 3,383,305 | 322,009 |
| Events in quadrant B | 2,109,121 | 368,430 |
| Events in quadrant C | 1,685,491 | 357,067 |
| Events in quadrant D | 2,549,613 | 308,162 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 66 | 0 |
| B | 0 | 66 | 0 |
| C | 0 | 66 | 0 |
| D | 0 | 66 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12333 | 1 |
| B | 0 | 8392 | 1 |
| C | 0 | 7050 | 1 |
| D | 0 | 9821 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3121 | 512 | 16.404998% |
| B | 3121 | 166 | 5.318808% |
| C | 3121 | 80 | 2.563281% |
| D | 3121 | 339 | 10.861903% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4251 | 3122 | 287 | 287 | 6.75% | 9.19% |  |
| B | 4251 | 3122 | 39 | 39 | 0.92% | 1.25% |  |
| C | 4251 | 3122 | 5 | 5 | 0.12% | 0.16% |  |
| D | 4251 | 3121 | 166 | 166 | 3.90% | 5.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 1124817 | 14520.49 | 369 | 360 | 77.4 |
| A | 10 | 83 | 802768 | 10361.76 | 369 | 360 | 77.4 |
| A | 13 | 248 | 13382 | 168.15 | 369 | 360 | 77.4 |
| B | 5 | 235 | 141157 | 1768.52 | 387 | 375 | 79.6 |
| B | 0 | 229 | 116788 | 1462.39 | 387 | 375 | 79.6 |
| B | 0 | 200 | 86504 | 1081.96 | 387 | 375 | 79.6 |
| C | 4 | 254 | 104477 | 1143.27 | 385 | 388 | 91.0 |
| C | 14 | 254 | 53548 | 583.89 | 385 | 388 | 91.0 |
| C | 1 | 3 | 8683 | 91.11 | 385 | 388 | 91.0 |
| D | 1 | 52 | 484103 | 5129.03 | 374 | 363 | 94.3 |
| D | 13 | 249 | 170070 | 1799.38 | 374 | 363 | 94.3 |
| D | 5 | 235 | 166087 | 1757.15 | 374 | 363 | 94.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
