| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_004T09_9000005992_44330cztM0_level2.fits | modeM0/AS1A13_004T09_9000005992_44330cztM0_level2_quad_clean.evt |
| Size (bytes) | 400,573,440 | 93,928,320 |
| Size | 382.0 MB | 89.6 MB |
| Events in quadrant A | 4,010,295 | 642,641 |
| Events in quadrant B | 3,056,938 | 644,829 |
| Events in quadrant C | 2,632,765 | 618,113 |
| Events in quadrant D | 4,699,177 | 552,934 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 8 |
| B | 0 | 116 | 4 |
| C | 0 | 118 | 6 |
| D | 0 | 119 | 7 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 1 |
| B | 0 | 15 | 4 |
| C | 0 | 13 | 2 |
| D | 0 | 14 | 3 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16853 | 236 |
| B | 0 | 12860 | 182 |
| C | 0 | 11870 | 195 |
| D | 0 | 17973 | 286 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5516 | 178 | 3.226976% |
| B | 5520 | 194 | 3.514493% |
| C | 5516 | 106 | 1.921682% |
| D | 5506 | 464 | 8.427170% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7411 | 5534 | 16 | 16 | 0.22% | 0.29% |  |
| B | 7411 | 5535 | 67 | 67 | 0.90% | 1.21% |  |
| C | 7411 | 5533 | 19 | 19 | 0.26% | 0.34% |  |
| D | 7411 | 5523 | 336 | 336 | 4.53% | 6.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1397741 | 10524.53 | 642 | 630 | 132.7 |
| A | 7 | 3 | 45435 | 337.52 | 642 | 630 | 132.7 |
| A | 0 | 243 | 37134 | 274.99 | 642 | 630 | 132.7 |
| B | 5 | 172 | 209487 | 1717.96 | 628 | 610 | 121.6 |
| B | 5 | 255 | 100916 | 824.99 | 628 | 610 | 121.6 |
| B | 0 | 199 | 75894 | 619.19 | 628 | 610 | 121.6 |
| C | 14 | 254 | 132723 | 911.37 | 623 | 627 | 144.9 |
| C | 1 | 3 | 62762 | 428.69 | 623 | 627 | 144.9 |
| C | 3 | 233 | 4895 | 29.45 | 623 | 627 | 144.9 |
| D | 2 | 153 | 714366 | 4653.95 | 616 | 598 | 153.4 |
| D | 13 | 249 | 682772 | 4447.95 | 616 | 598 | 153.4 |
| D | 5 | 171 | 213289 | 1386.8 | 616 | 598 | 153.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
