| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_008T08_9000005998_44397cztM0_level2.fits | modeM0/AS1A13_008T08_9000005998_44397cztM0_level2_quad_clean.evt |
| Size (bytes) | 462,257,280 | 110,433,600 |
| Size | 440.8 MB | 105.3 MB |
| Events in quadrant A | 4,945,933 | 731,006 |
| Events in quadrant B | 3,540,511 | 760,551 |
| Events in quadrant C | 3,170,030 | 732,696 |
| Events in quadrant D | 4,926,230 | 644,963 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20720 | 4 |
| B | 0 | 14784 | 2 |
| C | 0 | 14237 | 2 |
| D | 0 | 19168 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6802 | 197 | 2.896207% |
| B | 6802 | 159 | 2.337548% |
| C | 6802 | 76 | 1.117318% |
| D | 6802 | 408 | 5.998236% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7736 | 6802 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7736 | 6801 | 20 | 20 | 0.26% | 0.29% |  |
| C | 7736 | 6801 | 6 | 6 | 0.08% | 0.09% |  |
| D | 7736 | 6801 | 378 | 378 | 4.89% | 5.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1816983 | 11076.26 | 788 | 770 | 164.0 |
| A | 0 | 243 | 28588 | 169.65 | 788 | 770 | 164.0 |
| A | 8 | 4 | 23858 | 140.8 | 788 | 770 | 164.0 |
| B | 4 | 173 | 92523 | 585.84 | 789 | 765 | 156.6 |
| B | 0 | 219 | 72225 | 456.24 | 789 | 765 | 156.6 |
| B | 0 | 190 | 66142 | 417.41 | 789 | 765 | 156.6 |
| C | 14 | 254 | 87938 | 472.37 | 777 | 780 | 184.5 |
| C | 1 | 3 | 42183 | 224.39 | 777 | 780 | 184.5 |
| C | 3 | 233 | 12583 | 63.97 | 777 | 780 | 184.5 |
| D | 2 | 249 | 549134 | 2858.43 | 762 | 738 | 191.9 |
| D | 8 | 240 | 371974 | 1935.01 | 762 | 738 | 191.9 |
| D | 1 | 52 | 214556 | 1114.49 | 762 | 738 | 191.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
