| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_009T03_9000006006_44589cztM0_level2.fits | modeM0/AS1A13_009T03_9000006006_44589cztM0_level2_quad_clean.evt |
| Size (bytes) | 421,525,440 | 107,870,400 |
| Size | 402.0 MB | 102.9 MB |
| Events in quadrant A | 4,500,062 | 734,337 |
| Events in quadrant B | 3,084,963 | 756,705 |
| Events in quadrant C | 3,561,098 | 709,060 |
| Events in quadrant D | 3,983,393 | 640,927 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18639 | 3 |
| B | 0 | 12953 | 1 |
| C | 0 | 14503 | 1 |
| D | 0 | 15806 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6099 | 102 | 1.672405% |
| B | 6099 | 90 | 1.475652% |
| C | 6099 | 141 | 2.311854% |
| D | 6100 | 253 | 4.147541% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7314 | 6099 | 6 | 6 | 0.08% | 0.10% |  |
| B | 7314 | 6099 | 9 | 9 | 0.12% | 0.15% |  |
| C | 7314 | 6099 | 95 | 95 | 1.30% | 1.56% |  |
| D | 7315 | 6100 | 220 | 220 | 3.01% | 3.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1619870 | 10731.62 | 733 | 719 | 150.9 |
| A | 13 | 248 | 23404 | 150.35 | 733 | 719 | 150.9 |
| A | 10 | 248 | 16300 | 103.27 | 733 | 719 | 150.9 |
| B | 5 | 172 | 98689 | 682.37 | 733 | 712 | 143.6 |
| B | 0 | 155 | 60946 | 419.51 | 733 | 712 | 143.6 |
| B | 0 | 186 | 20401 | 137.13 | 733 | 712 | 143.6 |
| C | 12 | 2 | 475738 | 2820.65 | 717 | 725 | 168.4 |
| C | 14 | 254 | 160905 | 951.16 | 717 | 725 | 168.4 |
| C | 3 | 233 | 123276 | 727.71 | 717 | 725 | 168.4 |
| D | 13 | 249 | 652560 | 3651.7 | 708 | 686 | 178.5 |
| D | 1 | 52 | 342429 | 1914.4 | 708 | 686 | 178.5 |
| D | 2 | 249 | 80191 | 445.38 | 708 | 686 | 178.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
