| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_009T03_9000006006_44621cztM0_level2.fits | modeM0/AS1A13_009T03_9000006006_44621cztM0_level2_quad_clean.evt |
| Size (bytes) | 447,600,960 | 110,093,760 |
| Size | 426.9 MB | 105.0 MB |
| Events in quadrant A | 5,193,009 | 735,401 |
| Events in quadrant B | 3,265,419 | 764,867 |
| Events in quadrant C | 3,245,442 | 729,635 |
| Events in quadrant D | 4,352,874 | 644,831 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20855 | 8 |
| B | 0 | 14082 | 2 |
| C | 0 | 14249 | 4 |
| D | 0 | 17566 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6586 | 243 | 3.689645% |
| B | 6588 | 185 | 2.808136% |
| C | 6587 | 113 | 1.715500% |
| D | 6587 | 405 | 6.148474% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7558 | 6589 | 12 | 12 | 0.16% | 0.18% |  |
| B | 7558 | 6589 | 20 | 20 | 0.26% | 0.30% |  |
| C | 7558 | 6589 | 15 | 15 | 0.20% | 0.23% |  |
| D | 7558 | 6589 | 213 | 213 | 2.82% | 3.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1940476 | 11946.97 | 782 | 766 | 162.4 |
| A | 15 | 223 | 146156 | 895.48 | 782 | 766 | 162.4 |
| A | 13 | 248 | 57715 | 350.75 | 782 | 766 | 162.4 |
| B | 0 | 190 | 64545 | 405.91 | 787 | 763 | 157.1 |
| B | 5 | 172 | 54041 | 339.06 | 787 | 763 | 157.1 |
| B | 12 | 111 | 19956 | 122.14 | 787 | 763 | 157.1 |
| C | 12 | 2 | 113970 | 618.29 | 771 | 776 | 183.1 |
| C | 3 | 233 | 88288 | 478.01 | 771 | 776 | 183.1 |
| C | 14 | 254 | 17015 | 88.7 | 771 | 776 | 183.1 |
| D | 13 | 249 | 621829 | 3291.78 | 748 | 729 | 188.7 |
| D | 1 | 52 | 444334 | 2351.07 | 748 | 729 | 188.7 |
| D | 13 | 153 | 223162 | 1178.88 | 748 | 729 | 188.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
