| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_072T01_9000006008_44660cztM0_level2.fits | modeM0/AS1A13_072T01_9000006008_44660cztM0_level2_quad_clean.evt |
| Size (bytes) | 475,603,200 | 105,010,560 |
| Size | 453.6 MB | 100.1 MB |
| Events in quadrant A | 5,158,129 | 705,255 |
| Events in quadrant B | 3,120,884 | 736,894 |
| Events in quadrant C | 3,554,402 | 683,001 |
| Events in quadrant D | 5,274,438 | 607,321 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20609 | 1 |
| B | 0 | 13813 | 1 |
| C | 0 | 15218 | 1 |
| D | 0 | 20102 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6408 | 189 | 2.949438% |
| B | 6408 | 71 | 1.107990% |
| C | 6408 | 249 | 3.885768% |
| D | 6409 | 459 | 7.161804% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7528 | 6409 | 74 | 74 | 0.98% | 1.15% |  |
| B | 7528 | 6409 | 23 | 23 | 0.31% | 0.36% |  |
| C | 7528 | 6409 | 189 | 189 | 2.51% | 2.95% |  |
| D | 7529 | 6410 | 366 | 366 | 4.86% | 5.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1830455 | 12493.66 | 707 | 690 | 146.5 |
| A | 15 | 223 | 285749 | 1946.39 | 707 | 690 | 146.5 |
| A | 13 | 248 | 254137 | 1730.54 | 707 | 690 | 146.5 |
| B | 0 | 186 | 64314 | 464.04 | 712 | 691 | 137.1 |
| B | 0 | 183 | 60244 | 434.35 | 712 | 691 | 137.1 |
| B | 4 | 171 | 56015 | 403.51 | 712 | 691 | 137.1 |
| C | 12 | 2 | 618452 | 3796.14 | 692 | 695 | 162.7 |
| C | 14 | 254 | 174904 | 1070.52 | 692 | 695 | 162.7 |
| C | 2 | 14 | 21168 | 125.81 | 692 | 695 | 162.7 |
| D | 1 | 52 | 1932393 | 11312.6 | 681 | 660 | 170.8 |
| D | 13 | 249 | 153778 | 896.69 | 681 | 660 | 170.8 |
| D | 2 | 249 | 150096 | 875.12 | 681 | 660 | 170.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
