| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_077T01_9000006014_44705cztM0_level2.fits | modeM0/AS1A13_077T01_9000006014_44705cztM0_level2_quad_clean.evt |
| Size (bytes) | 360,884,160 | 74,943,360 |
| Size | 344.2 MB | 71.5 MB |
| Events in quadrant A | 3,427,293 | 517,938 |
| Events in quadrant B | 2,371,038 | 534,406 |
| Events in quadrant C | 2,092,087 | 508,019 |
| Events in quadrant D | 5,125,151 | 398,197 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13850 | 1 |
| B | 0 | 9913 | 1 |
| C | 0 | 9237 | 1 |
| D | 0 | 18346 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 92 | 0 |
| B | 0 | 92 | 0 |
| C | 0 | 92 | 0 |
| D | 0 | 92 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4411 | 78 | 1.768307% |
| B | 4411 | 84 | 1.904330% |
| C | 4410 | 19 | 0.430839% |
| D | 4410 | 743 | 16.848073% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5631 | 4412 | 11 | 11 | 0.20% | 0.25% |  |
| B | 5631 | 4412 | 23 | 23 | 0.41% | 0.52% |  |
| C | 5630 | 4411 | 3 | 3 | 0.05% | 0.07% |  |
| D | 5630 | 4411 | 572 | 572 | 10.16% | 12.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1349450 | 12407.63 | 521 | 511 | 108.7 |
| A | 13 | 248 | 20014 | 179.39 | 521 | 511 | 108.7 |
| A | 15 | 223 | 15400 | 136.95 | 521 | 511 | 108.7 |
| B | 5 | 172 | 109512 | 1062.37 | 520 | 505 | 102.6 |
| B | 0 | 190 | 43945 | 423.36 | 520 | 505 | 102.6 |
| B | 4 | 171 | 38449 | 369.8 | 520 | 505 | 102.6 |
| C | 14 | 254 | 40636 | 333.26 | 509 | 513 | 120.4 |
| C | 3 | 233 | 28609 | 233.36 | 509 | 513 | 120.4 |
| C | 1 | 3 | 13789 | 110.27 | 509 | 513 | 120.4 |
| D | 11 | 241 | 1270897 | 10323.64 | 477 | 462 | 123.1 |
| D | 13 | 249 | 1079055 | 8764.72 | 477 | 462 | 123.1 |
| D | 4 | 222 | 274801 | 2229.3 | 477 | 462 | 123.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
