| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_009T01_9000006016_44724cztM0_level2.fits | modeM0/AS1A13_009T01_9000006016_44724cztM0_level2_quad_clean.evt |
| Size (bytes) | 708,698,880 | 112,795,200 |
| Size | 675.9 MB | 107.6 MB |
| Events in quadrant A | 9,028,456 | 641,595 |
| Events in quadrant B | 4,362,246 | 806,145 |
| Events in quadrant C | 3,399,497 | 793,824 |
| Events in quadrant D | 8,859,748 | 648,666 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32709 | 7 |
| B | 0 | 18198 | 1 |
| C | 0 | 15878 | 1 |
| D | 0 | 31659 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7537 | 1822 | 24.174075% |
| B | 7537 | 337 | 4.471275% |
| C | 7538 | 96 | 1.273547% |
| D | 7538 | 1071 | 14.208013% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7617 | 7538 | 1156 | 1156 | 15.18% | 15.34% |  |
| B | 7617 | 7538 | 58 | 58 | 0.76% | 0.77% |  |
| C | 7618 | 7539 | 4 | 4 | 0.05% | 0.05% |  |
| D | 7618 | 7539 | 751 | 751 | 9.86% | 9.96% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 4105802 | 24706.91 | 789 | 772 | 166.1 |
| A | 10 | 83 | 1838447 | 11060.4 | 789 | 772 | 166.1 |
| A | 15 | 174 | 16151 | 92.56 | 789 | 772 | 166.1 |
| B | 0 | 189 | 573422 | 3266.96 | 862 | 833 | 175.3 |
| B | 0 | 190 | 148574 | 842.95 | 862 | 833 | 175.3 |
| B | 5 | 255 | 85598 | 483.63 | 862 | 833 | 175.3 |
| C | 14 | 254 | 28315 | 133.71 | 854 | 858 | 205.3 |
| C | 0 | 207 | 21114 | 98.65 | 854 | 858 | 205.3 |
| C | 1 | 3 | 14989 | 68.82 | 854 | 858 | 205.3 |
| D | 13 | 174 | 3139862 | 15323.21 | 810 | 785 | 204.9 |
| D | 1 | 52 | 1146339 | 5591.95 | 810 | 785 | 204.9 |
| D | 13 | 249 | 515917 | 2514.58 | 810 | 785 | 204.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
