| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_004T12_9000006020_44768cztM0_level2.fits | modeM0/AS1A13_004T12_9000006020_44768cztM0_level2_quad_clean.evt |
| Size (bytes) | 537,459,840 | 119,079,360 |
| Size | 512.6 MB | 113.6 MB |
| Events in quadrant A | 5,444,700 | 787,108 |
| Events in quadrant B | 4,254,399 | 800,143 |
| Events in quadrant C | 3,582,386 | 794,853 |
| Events in quadrant D | 6,026,580 | 697,540 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22942 | 2 |
| B | 0 | 17881 | 0 |
| C | 0 | 16252 | 0 |
| D | 0 | 23163 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7563 | 210 | 2.776676% |
| B | 7563 | 329 | 4.350126% |
| C | 7563 | 91 | 1.203226% |
| D | 7563 | 536 | 7.087135% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7563 | 7563 | 17 | 17 | 0.22% | 0.22% |  |
| B | 7563 | 7563 | 79 | 79 | 1.04% | 1.04% |  |
| C | 7563 | 7563 | 47 | 47 | 0.62% | 0.62% |  |
| D | 7563 | 7563 | 414 | 414 | 5.47% | 5.47% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2024826 | 11543.16 | 842 | 821 | 175.3 |
| A | 13 | 248 | 162031 | 919.4 | 842 | 821 | 175.3 |
| A | 3 | 137 | 10157 | 53.24 | 842 | 821 | 175.3 |
| B | 0 | 189 | 631470 | 3782.33 | 838 | 812 | 166.7 |
| B | 5 | 255 | 203823 | 1217.55 | 838 | 812 | 166.7 |
| B | 7 | 221 | 28600 | 166.66 | 838 | 812 | 166.7 |
| C | 14 | 254 | 137118 | 699.31 | 834 | 839 | 194.9 |
| C | 1 | 3 | 75204 | 381.6 | 834 | 839 | 194.9 |
| C | 12 | 2 | 64283 | 325.56 | 834 | 839 | 194.9 |
| D | 1 | 52 | 1317894 | 6530.11 | 811 | 785 | 201.7 |
| D | 2 | 249 | 486392 | 2407.6 | 811 | 785 | 201.7 |
| D | 7 | 38 | 438629 | 2170.79 | 811 | 785 | 201.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
