| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_004T12_9000006020_44779cztM0_level2.fits | modeM0/AS1A13_004T12_9000006020_44779cztM0_level2_quad_clean.evt |
| Size (bytes) | 79,528,320 | 10,676,160 |
| Size | 75.8 MB | 10.2 MB |
| Events in quadrant A | 954,751 | 65,549 |
| Events in quadrant B | 926,069 | 53,386 |
| Events in quadrant C | 323,028 | 80,962 |
| Events in quadrant D | 687,421 | 71,691 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3272 | 0 |
| B | 0 | 3161 | 0 |
| C | 0 | 1335 | 0 |
| D | 0 | 2472 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 637 | 171 | 26.844584% |
| B | 637 | 255 | 40.031397% |
| C | 637 | 1 | 0.156986% |
| D | 637 | 41 | 6.436421% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 637 | 637 | 143 | 143 | 22.45% | 22.45% |  |
| B | 637 | 637 | 239 | 239 | 37.52% | 37.52% |  |
| C | 637 | 637 | 3 | 3 | 0.47% | 0.47% |  |
| D | 637 | 637 | 51 | 51 | 8.01% | 8.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 264750 | 16230.05 | 69 | 68 | 16.3 |
| A | 10 | 83 | 239145 | 14659.98 | 69 | 68 | 16.3 |
| A | 15 | 223 | 157809 | 9672.53 | 69 | 68 | 16.3 |
| B | 4 | 171 | 637552 | 47082.95 | 59 | 58 | 13.5 |
| B | 0 | 189 | 23481 | 1729.94 | 59 | 58 | 13.5 |
| B | 5 | 255 | 19548 | 1439.46 | 59 | 58 | 13.5 |
| C | 3 | 233 | 16482 | 818.83 | 77 | 78 | 20.0 |
| C | 2 | 14 | 2163 | 104.08 | 77 | 78 | 20.0 |
| C | 14 | 254 | 577 | 24.91 | 77 | 78 | 20.0 |
| D | 1 | 52 | 199167 | 9705.83 | 76 | 73 | 20.5 |
| D | 2 | 249 | 118526 | 5774.58 | 76 | 73 | 20.5 |
| D | 13 | 249 | 25720 | 1250.29 | 76 | 73 | 20.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
