| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_004T13_9000006022_44793cztM0_level2.fits | modeM0/AS1A13_004T13_9000006022_44793cztM0_level2_quad_clean.evt |
| Size (bytes) | 549,872,640 | 106,102,080 |
| Size | 524.4 MB | 101.2 MB |
| Events in quadrant A | 6,041,485 | 696,008 |
| Events in quadrant B | 4,406,586 | 740,104 |
| Events in quadrant C | 2,979,795 | 738,766 |
| Events in quadrant D | 6,437,935 | 597,773 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22934 | 2 |
| B | 0 | 17359 | 2 |
| C | 0 | 13193 | 2 |
| D | 0 | 23479 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6305 | 484 | 7.676447% |
| B | 6304 | 360 | 5.710660% |
| C | 6304 | 29 | 0.460025% |
| D | 6304 | 856 | 13.578680% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7565 | 6306 | 382 | 382 | 5.05% | 6.06% |  |
| B | 7564 | 6305 | 281 | 281 | 3.71% | 4.46% |  |
| C | 7564 | 6305 | 12 | 12 | 0.16% | 0.19% |  |
| D | 7564 | 6305 | 806 | 806 | 10.66% | 12.78% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2064000 | 14225.56 | 703 | 687 | 145.0 |
| A | 15 | 223 | 1168255 | 8049.82 | 703 | 687 | 145.0 |
| A | 13 | 248 | 44463 | 301.81 | 703 | 687 | 145.0 |
| B | 0 | 189 | 996853 | 7190.87 | 714 | 693 | 138.5 |
| B | 5 | 255 | 238408 | 1715.97 | 714 | 693 | 138.5 |
| B | 5 | 172 | 82001 | 586.93 | 714 | 693 | 138.5 |
| C | 14 | 254 | 61084 | 355.84 | 722 | 727 | 169.6 |
| C | 2 | 14 | 35513 | 205.08 | 722 | 727 | 169.6 |
| C | 12 | 250 | 25132 | 143.88 | 722 | 727 | 169.6 |
| D | 13 | 249 | 984903 | 5871.3 | 676 | 657 | 167.6 |
| D | 5 | 235 | 939264 | 5599.05 | 676 | 657 | 167.6 |
| D | 13 | 174 | 440199 | 2621.99 | 676 | 657 | 167.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
