| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_012T01_9000006024_44806cztM0_level2.fits | modeM0/AS1A13_012T01_9000006024_44806cztM0_level2_quad_clean.evt |
| Size (bytes) | 411,560,640 | 52,246,080 |
| Size | 392.5 MB | 49.8 MB |
| Events in quadrant A | 6,075,072 | 255,790 |
| Events in quadrant B | 2,110,736 | 427,435 |
| Events in quadrant C | 1,703,302 | 411,883 |
| Events in quadrant D | 5,068,563 | 235,878 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20480 | 1 |
| B | 0 | 8540 | 1 |
| C | 0 | 7434 | 2 |
| D | 0 | 17446 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 72 | 0 |
| B | 0 | 72 | 0 |
| C | 0 | 72 | 0 |
| D | 0 | 72 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3549 | 1640 | 46.210200% |
| B | 3549 | 129 | 3.634827% |
| C | 3548 | 35 | 0.986471% |
| D | 3548 | 1323 | 37.288613% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4749 | 3549 | 1414 | 1414 | 29.77% | 39.84% |  |
| B | 4749 | 3549 | 52 | 52 | 1.09% | 1.47% |  |
| C | 4748 | 3548 | 3 | 3 | 0.06% | 0.08% |  |
| D | 4748 | 3548 | 1269 | 1269 | 26.73% | 35.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 3718415 | 50640.59 | 347 | 340 | 73.4 |
| A | 10 | 83 | 972222 | 13237.14 | 347 | 340 | 73.4 |
| A | 13 | 248 | 39926 | 539.17 | 347 | 340 | 73.4 |
| B | 0 | 168 | 141852 | 1646.71 | 429 | 416 | 85.9 |
| B | 0 | 189 | 84839 | 982.92 | 429 | 416 | 85.9 |
| B | 7 | 221 | 52790 | 609.78 | 429 | 416 | 85.9 |
| C | 14 | 254 | 17086 | 166.5 | 421 | 424 | 100.1 |
| C | 12 | 2 | 12461 | 120.28 | 421 | 424 | 100.1 |
| C | 1 | 3 | 11601 | 111.69 | 421 | 424 | 100.1 |
| D | 13 | 187 | 2164605 | 24963.93 | 339 | 329 | 86.7 |
| D | 5 | 235 | 630391 | 7267.48 | 339 | 329 | 86.7 |
| D | 11 | 241 | 374098 | 4311.25 | 339 | 329 | 86.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
