| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_012T01_9000006024_44810cztM0_level2.fits | modeM0/AS1A13_012T01_9000006024_44810cztM0_level2_quad_clean.evt |
| Size (bytes) | 526,904,640 | 79,888,320 |
| Size | 502.5 MB | 76.2 MB |
| Events in quadrant A | 7,357,648 | 447,000 |
| Events in quadrant B | 2,644,880 | 582,664 |
| Events in quadrant C | 2,437,937 | 553,007 |
| Events in quadrant D | 6,657,854 | 468,776 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25478 | 0 |
| B | 0 | 11366 | 0 |
| C | 0 | 11112 | 0 |
| D | 0 | 23518 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5240 | 1340 | 25.572519% |
| B | 5241 | 59 | 1.125739% |
| C | 5241 | 49 | 0.934936% |
| D | 5241 | 502 | 9.578325% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5239 | 5239 | 1285 | 1285 | 24.53% | 24.53% |  |
| B | 5240 | 5240 | 18 | 18 | 0.34% | 0.34% |  |
| C | 5241 | 5241 | 32 | 32 | 0.61% | 0.61% |  |
| D | 5240 | 5240 | 469 | 469 | 8.95% | 8.95% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 3880866 | 35727.57 | 517 | 505 | 108.6 |
| A | 10 | 83 | 1294271 | 11912.07 | 517 | 505 | 108.6 |
| A | 13 | 248 | 81472 | 745.49 | 517 | 505 | 108.6 |
| B | 5 | 255 | 112915 | 965.53 | 578 | 559 | 116.4 |
| B | 0 | 219 | 55736 | 474.16 | 578 | 559 | 116.4 |
| B | 0 | 155 | 46838 | 397.7 | 578 | 559 | 116.4 |
| C | 1 | 3 | 127634 | 951.58 | 566 | 571 | 133.5 |
| C | 14 | 254 | 55452 | 411.0 | 566 | 571 | 133.5 |
| C | 12 | 2 | 18230 | 132.25 | 566 | 571 | 133.5 |
| D | 13 | 187 | 2526203 | 18500.64 | 541 | 524 | 136.5 |
| D | 11 | 241 | 510321 | 3734.27 | 541 | 524 | 136.5 |
| D | 1 | 52 | 460692 | 3370.74 | 541 | 524 | 136.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
