| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_017T01_9000006028_44867cztM0_level2.fits | modeM0/AS1A13_017T01_9000006028_44867cztM0_level2_quad_clean.evt |
| Size (bytes) | 513,541,440 | 107,735,040 |
| Size | 489.8 MB | 102.7 MB |
| Events in quadrant A | 4,956,396 | 734,521 |
| Events in quadrant B | 3,433,876 | 757,511 |
| Events in quadrant C | 3,686,966 | 716,189 |
| Events in quadrant D | 6,435,131 | 606,440 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20025 | 1 |
| B | 0 | 14680 | 1 |
| C | 0 | 15549 | 1 |
| D | 0 | 23625 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6409 | 145 | 2.262443% |
| B | 6410 | 84 | 1.310452% |
| C | 6410 | 192 | 2.995320% |
| D | 6410 | 810 | 12.636505% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7519 | 6410 | 10 | 10 | 0.13% | 0.16% |  |
| B | 7520 | 6411 | 25 | 25 | 0.33% | 0.39% |  |
| C | 7520 | 6411 | 126 | 126 | 1.68% | 1.97% |  |
| D | 7520 | 6411 | 511 | 511 | 6.80% | 7.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2066576 | 13447.44 | 737 | 721 | 153.6 |
| A | 13 | 248 | 27214 | 172.45 | 737 | 721 | 153.6 |
| A | 7 | 3 | 10266 | 62.13 | 737 | 721 | 153.6 |
| B | 5 | 255 | 188683 | 1303.25 | 740 | 718 | 144.2 |
| B | 0 | 155 | 137454 | 948.05 | 740 | 718 | 144.2 |
| B | 0 | 168 | 36746 | 249.8 | 740 | 718 | 144.2 |
| C | 12 | 2 | 359934 | 2103.96 | 726 | 729 | 170.7 |
| C | 14 | 254 | 285159 | 1665.98 | 726 | 729 | 170.7 |
| C | 5 | 128 | 147077 | 857.2 | 726 | 729 | 170.7 |
| D | 1 | 52 | 2256667 | 13171.7 | 692 | 671 | 171.3 |
| D | 2 | 249 | 426349 | 2485.33 | 692 | 671 | 171.3 |
| D | 5 | 235 | 375306 | 2187.32 | 692 | 671 | 171.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
