| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_017T01_9000006028_44869cztM0_level2.fits | modeM0/AS1A13_017T01_9000006028_44869cztM0_level2_quad_clean.evt |
| Size (bytes) | 242,012,160 | 46,048,320 |
| Size | 230.8 MB | 43.9 MB |
| Events in quadrant A | 2,225,873 | 314,385 |
| Events in quadrant B | 1,661,173 | 321,654 |
| Events in quadrant C | 1,427,088 | 312,357 |
| Events in quadrant D | 3,425,718 | 246,087 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9465 | 715 |
| B | 0 | 7400 | 578 |
| C | 0 | 6585 | 452 |
| D | 0 | 13582 | 1480 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 62 | 4 |
| B | 0 | 62 | 4 |
| C | 0 | 61 | 3 |
| D | 0 | 61 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2796 | 84 | 3.004292% |
| B | 2800 | 118 | 4.214286% |
| C | 2815 | 19 | 0.674956% |
| D | 2763 | 509 | 18.422005% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3044 | 2836 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3122 | 2835 | 27 | 27 | 0.86% | 0.95% |  |
| C | 3128 | 2853 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3013 | 2805 | 267 | 267 | 8.86% | 9.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 859240 | 11519.37 | 347 | 337 | 74.6 |
| A | 7 | 3 | 11206 | 145.77 | 347 | 337 | 74.6 |
| A | 13 | 6 | 4645 | 57.78 | 347 | 337 | 74.6 |
| B | 5 | 255 | 133422 | 1856.28 | 348 | 336 | 71.7 |
| B | 0 | 186 | 58740 | 814.62 | 348 | 336 | 71.7 |
| B | 0 | 155 | 26673 | 367.35 | 348 | 336 | 71.7 |
| C | 12 | 2 | 22051 | 257.96 | 350 | 351 | 84.1 |
| C | 2 | 14 | 19124 | 223.16 | 350 | 351 | 84.1 |
| C | 3 | 233 | 8060 | 91.64 | 350 | 351 | 84.1 |
| D | 1 | 52 | 1002069 | 11941.83 | 321 | 309 | 83.9 |
| D | 13 | 174 | 508157 | 6053.98 | 321 | 309 | 83.9 |
| D | 5 | 235 | 291402 | 3470.08 | 321 | 309 | 83.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
