| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_017T02_9000006032_44939cztM0_level2.fits | modeM0/AS1A13_017T02_9000006032_44939cztM0_level2_quad_clean.evt |
| Size (bytes) | 696,081,600 | 107,040,960 |
| Size | 663.8 MB | 102.1 MB |
| Events in quadrant A | 5,931,956 | 788,343 |
| Events in quadrant B | 4,180,415 | 822,794 |
| Events in quadrant C | 3,372,763 | 802,696 |
| Events in quadrant D | 11,763,238 | 361,055 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22181 | 2 |
| B | 0 | 16795 | 2 |
| C | 0 | 14253 | 2 |
| D | 0 | 39580 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6686 | 284 | 4.247682% |
| B | 6686 | 234 | 3.499850% |
| C | 6686 | 105 | 1.570446% |
| D | 6686 | 3504 | 52.408017% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7811 | 6687 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7811 | 6687 | 52 | 52 | 0.67% | 0.78% |  |
| C | 7811 | 6687 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7811 | 6687 | 3057 | 3057 | 39.14% | 45.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2625173 | 15211.94 | 832 | 815 | 172.5 |
| A | 13 | 248 | 34126 | 193.09 | 832 | 815 | 172.5 |
| A | 0 | 243 | 30431 | 171.67 | 832 | 815 | 172.5 |
| B | 4 | 171 | 283509 | 1737.47 | 830 | 806 | 162.7 |
| B | 5 | 255 | 114230 | 697.1 | 830 | 806 | 162.7 |
| B | 0 | 155 | 95583 | 582.49 | 830 | 806 | 162.7 |
| C | 3 | 233 | 76292 | 391.55 | 828 | 835 | 192.7 |
| C | 14 | 254 | 29762 | 150.11 | 828 | 835 | 192.7 |
| C | 15 | 208 | 16825 | 82.97 | 828 | 835 | 192.7 |
| D | 13 | 187 | 7451557 | 51416.76 | 559 | 542 | 144.9 |
| D | 1 | 52 | 609256 | 4200.51 | 559 | 542 | 144.9 |
| D | 5 | 171 | 419057 | 2888.02 | 559 | 542 | 144.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
