| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_017T02_9000006032_44961cztM0_level2.fits | modeM0/AS1A13_017T02_9000006032_44961cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,083,561,920 | 381,493,440 |
| Size | 1.9 GB | 363.8 MB |
| Events in quadrant A | 18,939,803 | 2,596,371 |
| Events in quadrant B | 14,165,668 | 2,643,219 |
| Events in quadrant C | 11,437,079 | 2,617,200 |
| Events in quadrant D | 30,704,232 | 2,014,856 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 496 | 0 |
| B | 0 | 496 | 0 |
| C | 0 | 496 | 0 |
| D | 0 | 496 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 75369 | 3 |
| B | 0 | 59228 | 3 |
| C | 0 | 51574 | 3 |
| D | 0 | 108245 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 24381 | 499 | 2.046676% |
| B | 24382 | 915 | 3.752768% |
| C | 24381 | 138 | 0.566015% |
| D | 24381 | 4516 | 18.522620% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 25901 | 24385 | 9 | 9 | 0.03% | 0.04% |  |
| B | 25902 | 24386 | 365 | 365 | 1.41% | 1.50% |  |
| C | 25901 | 24385 | 44 | 44 | 0.17% | 0.18% |  |
| D | 25901 | 24385 | 4001 | 4001 | 15.45% | 16.41% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 7979784 | 13722.95 | 2788 | 2722 | 581.3 |
| A | 13 | 248 | 73300 | 121.41 | 2788 | 2722 | 581.3 |
| A | 0 | 243 | 41885 | 67.37 | 2788 | 2722 | 581.3 |
| B | 4 | 171 | 1203181 | 2207.47 | 2763 | 2679 | 543.8 |
| B | 5 | 255 | 731559 | 1340.26 | 2763 | 2679 | 543.8 |
| B | 5 | 172 | 502186 | 918.49 | 2763 | 2679 | 543.8 |
| C | 12 | 250 | 389427 | 598.07 | 2754 | 2772 | 646.5 |
| C | 3 | 233 | 98767 | 148.48 | 2754 | 2772 | 646.5 |
| C | 14 | 254 | 90443 | 135.61 | 2754 | 2772 | 646.5 |
| D | 13 | 187 | 8438611 | 13073.93 | 2540 | 2461 | 645.3 |
| D | 12 | 33 | 5340768 | 8273.04 | 2540 | 2461 | 645.3 |
| D | 1 | 52 | 1560729 | 2414.93 | 2540 | 2461 | 645.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
